RF Antennas
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | RF Family/Standard | Frequency Group | Frequency (Center/Band) | Frequency Range | Antenna Type | Number of Bands | VSWR | Return Loss | Gain | Power - Max | Features | Termination | Ingress Protection | Grade | Qualification | Mounting Type | Height (Max) | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
ANT2405F001R0169ARF ANT 169MHZ CHIP SOLDER SMD |
0 |
|
- |
2405 | Tape & Reel (TR) | Active | - | VHF (f < 300MHz) | 169MHz | 168MHz ~ 179MHz | Chip | 1 | - | -18dB | - | - | - | Solder | - | - | - | Surface Mount | 0.063" (1.60mm) | - |
|
H2UE6P1K2G0100UNICTRON CC40D7 - GSM & 3G, CHIP |
0 |
|
- |
- | Tape & Reel (TR) | Active | Cellular | UHF (300MHz ~ 1GHz), UHF (1GHz ~ 2GHz) | 892MHz, 1.94GHz | 824MHz ~ 960MHz, 1.71GHz ~ 2.17GHz | Chip | 2 | 3 | - | 1.7dBi, 2.9dBi | 2 W | - | Solder | - | - | - | Surface Mount | 0.126" (3.20mm) | 2G, 3G, GSM |
|
SRFWG018-100RF ANT 1.561/1.575GHZ FLAT 100MM |
0 |
|
Datasheet |
Asper | Bulk | Active | Bluetooth, Navigation, WiFi | UHF (1GHz ~ 2GHz), UHF (2GHz ~ 3GHz) | 1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz | 1.559GHz ~ 1.609GHz, 2.4GHz ~ 2.5GHz | Flat Patch | 2 | 1.4 | -18dB | 5.6dBi | - | Cable - 100mm | U.FL (UMCC), I-PEX MHF1 (2) | - | - | - | Adhesive | 0.006" (0.15mm) | Bluetooth, GNSS, Wi-Fi |
|
ANT-2.4-FPC-SF150M4ANT 2.4 FPC 25X20 150 CBL MHF4 |
0 |
|
Datasheet |
ANT-2.4-FPC-SF | Bag | Active | 802.15.4, Bluetooth, General ISM, WiFi | UHF (2GHz ~ 3GHz) | 2.45GHz | 2.4GHz ~ 2.5GHz | PCB Trace | 1 | 1.9 | - | 3.9dBi | 2 W | Cable - 150mm | MHF4 | - | - | - | Adhesive | 0.004" (0.10mm) | Bluetooth, ISM, Wi-Fi, Zigbee™ |
|
ANT-2.4-FPC-SH150M4ANT 2.4 FPC 25X20 150 CBL MHF4 |
0 |
|
Datasheet |
ANT-2.4-FPC-SH | Bag | Active | 802.15.4, Bluetooth, General ISM, WiFi | UHF (2GHz ~ 3GHz) | 2.45GHz | 2.4GHz ~ 2.5GHz | PCB Trace | 1 | 1.4 | - | 4dBi | 2 W | Cable - 150mm | MHF4 | - | - | - | Adhesive | 0.004" (0.10mm) | Bluetooth, ISM, Wi-Fi, Zigbee™ |
|
|
AFC8513U4GS-0050S5G/4G/LTE FLEXIBLE ANTENNA |
0 |
|
Datasheet |
AFC | Bulk | Active | Cellular, Navigation, WiFi | Wide Band | 2.349GHz | 698MHz ~ 4GHz | Flat Patch | 1 | 3 | - | 5dBi | 5 W | Cable - 50mm | I-PEX1 Female | - | - | - | Adhesive | 0.008" (0.20mm) | 2G, 3G, 4G, 5G, BeiDou, GNSS, GLONASS, GSM, IoT, M2M, QZSS, Wi-Fi |
|
SRF2I019-150RF ANT 868MHZ/915MHZ FLAT PATCH |
0 |
|
Datasheet |
Montana | Bulk | Active | General ISM | UHF (300MHz ~ 1GHz) | 868MHz, 915MHz | 863MHz ~ 870MHz, 902MHz ~ 928MHz | Flat Patch | 2 | 1.7 | -11dB | 1.9dBi | - | Cable - 150mm | U.FL (UMCC), I-PEX MHF1 | - | - | - | Adhesive | 0.006" (0.15mm) | ISM |
|
|
SRFWG018-150RF ANT 1.561/1.575GHZ FLAT 150MM |
0 |
|
Datasheet |
Asper | Bulk | Active | Bluetooth, Navigation, WiFi | UHF (1GHz ~ 2GHz), UHF (2GHz ~ 3GHz) | 1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz | 1.559GHz ~ 1.609GHz, 2.4GHz ~ 2.5GHz | Flat Patch | 2 | 1.4 | -18dB | 5.6dBi | - | Cable - 150mm | U.FL (UMCC), I-PEX MHF1 (2) | - | - | - | Adhesive | 0.006" (0.15mm) | Bluetooth, GNSS, Wi-Fi |
|
|
SRFI028-200INCA 433MHZ ANTENNA - 200MM CABL |
0 |
|
Datasheet |
FlexiiANT® | Bulk | Active | General ISM | UHF (300MHz ~ 1GHz) | 433MHz | 432MHz ~ 434MHz | PCB Trace | 1 | 1.6 | -11dB | 2.8dBi | - | Cable - 200mm | U.FL (UMCC), I-PEX MHF | - | - | - | Adhesive | 0.006" (0.15mm) | ISM |
|
|
YEIM001AAEXTERNAL ANTENNA,470MHZ |
0 |
|
Datasheet |
- | Bulk | Active | General ISM | UHF (300MHz ~ 1GHz) | 470MHz | 465MHz ~ 475MHz | Whip, Straight | 1 | - | - | - | - | Cable - 2m | SMA Male | - | - | - | Magnetic | 5.157" (131.00mm) | ISM |
|
|
SRFWG018-200RF ANT 1.561/1.575GHZ FLAT 200MM |
0 |
|
Datasheet |
Asper | Bulk | Active | Bluetooth, Navigation, WiFi | UHF (1GHz ~ 2GHz), UHF (2GHz ~ 3GHz) | 1.561GHz, 1.575GHz, 1.602GHz, 2.4GHz | 1.559GHz ~ 1.609GHz, 2.4GHz ~ 2.5GHz | Flat Patch | 2 | 1.3, 1.4 | -18.4dB, -14.5dB | 4.25dBi, 5.6dBi | - | Cable - 200mm | U.FL (UMCC), I-PEX MHF1 (2) | - | - | - | Adhesive | 0.006" (0.15mm) | Bluetooth, GNSS, Wi-Fi |
|
|
W6102B0150ANTENNA INFRASTRUCT |
0 |
|
- |
* | Bag | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
ANT-W63RPC1-50RF ANT WIFI 6GHZ FLEX ADHES 50MM |
0 |
|
Datasheet |
W63RPC | Bag | Active | WiFi | Wide Band | 2.4GHz, 5GHz, 6GHz | 2.4GHz ~ 2.485GHz, 5.15GHz ~ 5.85GHz, 5.925GHz ~ 7.125GHz | Rigid Patch | 3 | 1.8, 2.1, 1.6 | -10.9dB, -9dB, -12.7dB | 3.7dBi, 6.1dBi, 5.9dBi | 5 W | Cable - 50mm | Solder | - | - | - | Adhesive | 0.051" (1.30mm) | 802.11, 802.15.4, Bluetooth, U-NII, Wi-Fi 4, Wi-Fi 5, Wi-Fi 6, Wi-Fi 6E, Zigbee |
|
APAM1068JL01V2.0RF ANT 1.575GHZ CER PATCH IPEX |
0 |
|
Datasheet |
APAM | Tray | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.575GHz | 1.574GHz ~ 1.576GHz | Ceramic Patch | 1 | 1.5 | - | -2dBic | - | - | U.FL (UMCC), I-PEX MHF1 | - | - | - | Surface Mount | 0.268" (6.80mm) | GPS |
|
APAM1268JL02V2.0RF ANT 1.575GHZ CER PATCH IPEX |
0 |
|
Datasheet |
APAM | Tray | Active | Navigation | UHF (1GHz ~ 2GHz) | 1.575GHz | 1.573GHz ~ 1.577GHz | Ceramic Patch | 1 | 1.5 | - | 0dBic | - | - | U.FL (UMCC), I-PEX MHF1 | - | - | - | Surface Mount | 0.268" (6.80mm) | GPS |
|
PE511950 DBI PCB ANT 824-960MHZ UMCX |
7 |
|
Datasheet |
- | Bag | Active | Cellular | UHF (300MHz ~ 1GHz) | 892MHz | 824MHz ~ 960MHz | PCB Trace | 1 | 3 | - | 0dBi | 1 W | Cable - 100mm | U.FL (UMCX), I-PEX | - | - | - | Surface Mount | - | - |
|
|
ANT-2.4-FPC-SF200M4ANT 2.4 FPC 25X20 200 CBL MHF4 |
0 |
|
Datasheet |
ANT-2.4-FPC-SF | Bag | Active | 802.15.4, Bluetooth, General ISM, WiFi | UHF (2GHz ~ 3GHz) | 2.45GHz | 2.4GHz ~ 2.5GHz | PCB Trace | 1 | 1.9 | - | 3.9dBi | 2 W | Cable - 200mm | MHF4 | - | - | - | Adhesive | 0.004" (0.10mm) | Bluetooth, ISM, Wi-Fi, Zigbee™ |
|
|
ANT-2.4-FPC-SH200M4ANT 2.4 FPC 25X20 200 CBL MHF4 |
0 |
|
Datasheet |
ANT-2.4-FPC-SH | Bag | Active | 802.15.4, Bluetooth, General ISM, WiFi | UHF (2GHz ~ 3GHz) | 2.45GHz | 2.4GHz ~ 2.5GHz | PCB Trace | 1 | 1.4 | - | 4dBi | 2 W | Cable - 200mm | MHF4 | - | - | - | Adhesive | 0.004" (0.10mm) | Bluetooth, ISM, Wi-Fi, Zigbee™ |
|
|
SRF2I019-200RF ANT 868MHZ/915MHZ FLAT PATCH |
0 |
|
Datasheet |
Montana | Bulk | Active | General ISM | UHF (300MHz ~ 1GHz) | 868MHz, 915MHz | 863MHz ~ 870MHz, 902MHz ~ 928MHz | Flat Patch | 2 | 1.7 | -11dB | 1.9dBi | - | Cable - 200mm | U.FL (UMCC), I-PEX MHF1 | - | - | - | Adhesive | 0.006" (0.15mm) | ISM |
|
|
ST0226-40-501-BRF ANTENNA EXTERNAL WI-FI DUAL-B |
0 |
|
- |
- | Box | Active | WiFi | UHF (2GHz ~ 3GHz), SHF (f > 4GHz) | 2.45GHz, 5.4875GHz | 2.4GHz ~ 2.5GHz, 5.15GHz ~ 5.825GHz | Whip, Straight | 2 | - | -10dB | 3.5dBi, 5.7dBi | 1 W | - | RP-SMA | IP65 | - | - | Connector Mount | 7.874" (200.00mm) | Wi-Fi |
RF Antennas Electronic Components
Frequently Asked Questions
Q1: What products are included in RF Antennas?
This category includes related RF Antennas subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for RF Antennas components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for RF Antennas and other electronic components.
