Resistor Networks, Arrays
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Circuit Type | Resistance (Ohms) | Tolerance | Number of Resistors | Resistor Matching Ratio | Resistor-Ratio-Drift | Number of Pins | Power Per Element | Temperature Coefficient | Operating Temperature | Grade | Qualification | Applications | Mounting Type | Supplier Device Package | Size / Dimension | Height - Seated (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
4612X-102-102LFRES ARRAY 6 RES 1K OHM 12SIP |
5,602 |
|
Datasheet |
4600X | 12-SIP | Bulk | Active | Isolated | 1k | ±2% | 6 | - | - | 12 | 300mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 12-SIP | 1.198" L x 0.098" W (30.43mm x 2.49mm) | 0.200" (5.08mm) |
|
4614X-104-331/471LRES NTWRK 24 RES MULT OHM 14SIP |
1,185 |
|
Datasheet |
4600X | 14-SIP | Bulk | Active | Dual Terminator | 330, 470 | ±2% | 24 | - | - | 14 | 200mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 14-SIP | 1.398" L x 0.098" W (35.51mm x 2.49mm) | 0.200" (5.08mm) |
|
4116R-1-682LFRES ARRAY 8 RES 6.8K OHM 16DIP |
751 |
|
Datasheet |
4100R | 16-DIP (0.300", 7.62mm) | Tube | Active | Isolated | 6.8k | ±2% | 8 | - | 50ppm/°C | 16 | 250mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 16-DIP | 0.865" L x 0.300" W (21.97mm x 7.62mm) | 0.185" (4.69mm) |
|
4816P-1-272LFRES ARRAY 8 RES 2.7K OHM 16SOIC |
3,598 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tape & Reel (TR) | Active | Isolated | 2.7k | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-1-270LFRES ARRAY 8 RES 27 OHM 16SOIC |
1,984 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tape & Reel (TR) | Active | Isolated | 27 | ±1Ohm | 8 | - | - | 16 | 160mW | ±250ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4116R-1-270LFRES ARRAY 8 RES 27 OHM 16DIP |
1,197 |
|
Datasheet |
4100R | 16-DIP (0.300", 7.62mm) | Tube | Active | Isolated | 27 | ±1Ohm | 8 | - | 50ppm/°C | 16 | 250mW | ±250ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 16-DIP | 0.865" L x 0.300" W (21.97mm x 7.62mm) | 0.185" (4.69mm) |
|
4114R-2-472LFRES ARRAY 13 RES 4.7K OHM 14DIP |
427 |
|
Datasheet |
4100R | 14-DIP (0.300", 7.62mm) | Tube | Active | Bussed | 4.7k | ±2% | 13 | - | 50ppm/°C | 14 | 125mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 14-DIP | 0.765" L x 0.300" W (19.43mm x 7.62mm) | 0.185" (4.69mm) |
|
4814P-1-331LFRES ARRAY 7 RES 330 OHM 14SOIC |
1,683 |
|
Datasheet |
4800P | 14-SOIC (0.220", 5.59mm Width) | Tape & Reel (TR) | Active | Isolated | 330 | ±2% | 7 | - | - | 14 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 14-SOM | 0.390" L x 0.220" W (9.91mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-1-271LFRES ARRAY 8 RES 270 OHM 16SOIC |
6,455 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tape & Reel (TR) | Active | Isolated | 270 | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-2-332LFRES ARRAY 15 RES 3.3K OHM 16SOIC |
1,524 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tape & Reel (TR) | Active | Bussed | 3.3k | ±2% | 15 | - | - | 16 | 80mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-1-680LFRES ARRAY 8 RES 68 OHM 16SOIC |
420 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tape & Reel (TR) | Active | Isolated | 68 | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-T01-202LFRES ARRAY 8 RES 2K OHM 16SOIC |
1,667 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tube | Active | Isolated | 2k | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-T01-153LFRES ARRAY 8 RES 15K OHM 16SOIC |
1,633 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tube | Active | Isolated | 15k | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-T01-151LFRES ARRAY 8 RES 150 OHM 16SOIC |
1,608 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tube | Active | Isolated | 150 | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-T01-330LFRES ARRAY 8 RES 33 OHM 16SOIC |
467 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tube | Active | Isolated | 33 | ±1Ohm | 8 | - | - | 16 | 160mW | ±250ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
4308R-101-104LFRES ARRAY 7 RES 100K OHM 8SIP |
363 |
|
Datasheet |
4300R | 8-SIP | Tube | Active | Bussed | 100k | ±2% | 7 | - | 50ppm/°C | 8 | 200mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 8-SIP | 0.784" L x 0.085" W (19.91mm x 2.16mm) | 0.195" (4.95mm) |
|
|
4816P-T01-221LFRES ARRAY 8 RES 220 OHM 16SOIC |
5,787 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tube | Active | Isolated | 220 | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
|
4816P-T01-203LFRES ARRAY 8 RES 20K OHM 16SOIC |
1,440 |
|
Datasheet |
4800P | 16-SOIC (0.220", 5.59mm Width) | Tube | Active | Isolated | 20k | ±2% | 8 | - | - | 16 | 160mW | ±100ppm/°C | -55°C ~ 125°C | Automotive | AEC-Q200 | - | Surface Mount | 16-SOM | 0.440" L x 0.220" W (11.18mm x 5.59mm) | 0.094" (2.40mm) |
|
4310R-101-272LFRES ARRAY 9 RES 2.7K OHM 10SIP |
510 |
|
Datasheet |
4300R | 10-SIP | Tube | Active | Bussed | 2.7k | ±2% | 9 | - | 50ppm/°C | 10 | 200mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 10-SIP | 0.984" L x 0.085" W (24.99mm x 2.16mm) | 0.195" (4.95mm) |
|
|
4116R-1-181LFRES ARRAY 8 RES 180 OHM 16DIP |
1,972 |
|
Datasheet |
4100R | 16-DIP (0.300", 7.62mm) | Tube | Active | Isolated | 180 | ±2% | 8 | - | 50ppm/°C | 16 | 250mW | ±100ppm/°C | -55°C ~ 125°C | - | - | - | Through Hole | 16-DIP | 0.865" L x 0.300" W (21.97mm x 7.62mm) | 0.185" (4.69mm) |
