Single Diodes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Voltage - Forward (Vf) (Max) @ If | Speed | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Capacitance @ Vr, F | Grade | Qualification | Mounting Type | Supplier Device Package | Operating Temperature - Junction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
BAT43DIODE SCHOTTKY 30V 200MA DO35 |
31,751 |
|
Datasheet |
- | DO-204AH, DO-35, Axial | Tape & Reel (TR) | Active | Schottky | 30 V | 200mA | 1 V @ 200 mA | Small Signal =< 200mA (Io), Any Speed | 5 ns | 500 nA @ 25 V | 7pF @ 1V, 1MHz | - | - | Through Hole | DO-35 | -65°C ~ 125°C |
|
CTS05S40,L3FDIODE SCHOTTKY 40V 500MA CST2 |
30,758 |
|
Datasheet |
- | SOD-882 | Tape & Reel (TR) | Active | Schottky | 40 V | 500mA | 350 mV @ 100 mA | Fast Recovery =< 500ns, > 200mA (Io) | - | 30 µA @ 10 V | 42pF @ 0V, 1MHz | - | - | Surface Mount | CST2 | 125°C (Max) |
|
1N4002RLGDIODE GEN PURP 100V 1A AXIAL |
28,108 |
|
Datasheet |
- | DO-204AL, DO-41, Axial | Tape & Reel (TR) | Active | Standard | 100 V | 1A | 1.1 V @ 1 A | Standard Recovery >500ns, > 200mA (Io) | - | 10 µA @ 100 V | - | - | - | Through Hole | Axial | -65°C ~ 175°C |
|
SS10200FL_R1_00001SOD-123FL, SKY |
25,647 |
|
Datasheet |
- | SOD-123F | Tape & Reel (TR) | Active | Schottky | 200 V | 1A | 850 mV @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 30 µA @ 200 V | - | - | - | Surface Mount | SOD-123FL | -55°C ~ 150°C |
.jpg)
|
BAS521,135DIODE GEN PURP 300V 250MA SOD523 |
25,549 |
|
Datasheet |
- | SC-79, SOD-523 | Tape & Reel (TR) | Active | Standard | 300 V | 250mA | 1.1 V @ 100 mA | Fast Recovery =< 500ns, > 200mA (Io) | 50 ns | 150 nA @ 250 V | 5pF @ 0V, 1MHz | - | - | Surface Mount | SOD-523 | 150°C (Max) |
|
1N5817-TPDIODE SCHOTTKY 20V 1A DO41 |
24,893 |
|
Datasheet |
- | DO-204AL, DO-41, Axial | Tape & Reel (TR) | Active | Schottky | 20 V | 1A | 450 mV @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 1 mA @ 20 V | 110pF @ 4V, 1MHz | - | - | Through Hole | DO-41 | -55°C ~ 125°C |
|
BAR46FILMDIODE SCHOTTKY 100V 150MA SOT23 |
24,545 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Active | Schottky | 100 V | 150mA | 1 V @ 250 mA | Small Signal =< 200mA (Io), Any Speed | - | 5 µA @ 75 V | 10pF @ 0V, 1MHz | - | - | Surface Mount | SOT-23 | 150°C (Max) |
|
GS2M-LTPDIODE GEN PURP 1KV 2A DO214AC |
21,882 |
|
Datasheet |
- | DO-214AC, SMA | Tape & Reel (TR) | Active | Standard | 1000 V | 2A | 1.1 V @ 2 A | Standard Recovery >500ns, > 200mA (Io) | - | 5 µA @ 1000 V | 20pF @ 4V, 1MHz | - | - | Surface Mount | DO-214AC (SMA) | -55°C ~ 150°C |
|
1SS427,L3MDIODE GEN PURP 80V 100MA SOD923 |
21,295 |
|
Datasheet |
- | SOD-923 | Tape & Reel (TR) | Active | Standard | 80 V | 100mA | 1.2 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | 1.6 ns | 500 nA @ 80 V | 0.3pF @ 0V, 1MHz | - | - | Surface Mount | SOD-923 | -55°C ~ 150°C |
|
SDMK0340L-7-FDIODE SCHOTTKY 40V 30MA SOD323 |
20,947 |
|
Datasheet |
- | SC-76, SOD-323 | Tape & Reel (TR) | Active | Schottky | 40 V | 30mA | 370 mV @ 1 mA | Small Signal =< 200mA (Io), Any Speed | - | 500 nA @ 30 V | 2pF @ 1V, 1MHz | - | - | Surface Mount | SOD-323 | -40°C ~ 125°C |
|
RB751V-40DIODE SCHOTTKY 30V 30MA SOD323 |
20,877 |
|
Datasheet |
- | SC-76, SOD-323 | Tape & Reel (TR) | Active | Schottky | 30 V | 30mA | 370 mV @ 1 mA | Small Signal =< 200mA (Io), Any Speed | - | 500 nA @ 30 V | 2pF @ 1V, 1MHz | - | - | Surface Mount | SOD-323 | 125°C (Max) |
|
RB520S-40-TPDIODE SCHOTTKY 40V 200MA SOD523 |
20,355 |
|
Datasheet |
- | SC-79, SOD-523 | Tape & Reel (TR) | Active | Schottky | 40 V | 200mA | 550 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 10 µA @ 40 V | - | - | - | Surface Mount | SOD-523 | 125°C (Max) |
|
ES1D-LTPDIODE GEN PURP 200V 1A DO214AC |
20,346 |
|
Datasheet |
- | DO-214AC, SMA | Tape & Reel (TR) | Active | Standard | 200 V | 1A | 950 mV @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 35 ns | 5 µA @ 200 V | 15pF @ 4V, 1MHz | - | - | Surface Mount | DO-214AC (SMA) | -65°C ~ 175°C |
|
1PS76SB40,115DIODE SCHOTTKY 40V 120MA SOD323 |
17,863 |
|
Datasheet |
- | SC-76, SOD-323 | Tape & Reel (TR) | Active | Schottky | 40 V | 120mA | 1 V @ 40 mA | Small Signal =< 200mA (Io), Any Speed | - | 10 µA @ 40 V | 5pF @ 0V, 1MHz | - | - | Surface Mount | SOD-323 | 150°C (Max) |
|
US1JDIODE GEN PURP 600V 1A SMA |
17,248 |
|
Datasheet |
- | DO-214AC, SMA | Tape & Reel (TR) | Active | Standard | 600 V | 1A | 1.7 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | 75 ns | 5 µA @ 600 V | - | - | - | Surface Mount | DO-214AC (SMA) | -50°C ~ 150°C |
|
V1PM15-M3/HDIODE SCHOTTKY 150V 1A MICROSMP |
16,210 |
|
Datasheet |
eSMP® | DO-219AD | Tape & Reel (TR) | Active | Schottky | 150 V | 1A | 1.21 V @ 1 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 50 µA @ 150 V | 65pF @ 4V, 1MHz | - | - | Surface Mount | DO-219AD (MicroSMP) | -40°C ~ 175°C |
|
SDM20U40-7DIODE SCHOTTKY 40V 250MA SOD523 |
15,089 |
|
Datasheet |
- | SC-79, SOD-523 | Tape & Reel (TR) | Active | Schottky | 40 V | 250mA | 600 mV @ 200 mA | Fast Recovery =< 500ns, > 200mA (Io) | 10 ns | 5 µA @ 30 V | 50pF @ 0V, 1MHz | - | - | Surface Mount | SOD-523 | -65°C ~ 125°C |
|
1N4006-E3/54DIODE GEN PURP 800V 1A DO204AL |
14,995 |
|
Datasheet |
- | DO-204AL, DO-41, Axial | Tape & Reel (TR) | Active | Standard | 800 V | 1A | 1.1 V @ 1 A | Standard Recovery >500ns, > 200mA (Io) | - | 5 µA @ 800 V | 15pF @ 4V, 1MHz | - | - | Through Hole | DO-204AL (DO-41) | -55°C ~ 150°C |
|
BAS16LTH-G3-08DIODE GP 100V 250MA DFN1006-2A |
13,664 |
|
Datasheet |
- | 0402 (1006 Metric) | Tape & Reel (TR) | Active | Standard | 100 V | 250mA | 1.25 V @ 150 mA | Fast Recovery =< 500ns, > 200mA (Io) | 4 ns | 1 µA @ 100 V | 0.36pF @ 0V, 1MHz | Automotive | AEC-Q101 | Surface Mount | DFN1006-2A | -55°C ~ 175°C |
|
1SS416,L3MDIODE SCHOTTKY 30V 100MA SOD923 |
11,909 |
|
Datasheet |
- | SOD-923 | Tape & Reel (TR) | Active | Schottky | 30 V | 100mA | 500 mV @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 50 µA @ 30 V | 15pF @ 0V, 1MHz | - | - | Surface Mount | SOD-923 | 125°C (Max) |
Single Diodes Electronic Components
Explore Single Diodes electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
