Single Diodes
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Voltage - DC Reverse (Vr) (Max) | Current - Average Rectified (Io) | Voltage - Forward (Vf) (Max) @ If | Speed | Reverse Recovery Time (trr) | Current - Reverse Leakage @ Vr | Capacitance @ Vr, F | Grade | Qualification | Mounting Type | Supplier Device Package | Operating Temperature - Junction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
JAN1N5196US/TRSIGNAL OR COMPUTER DIODE |
7,809 |
|
Datasheet |
- | SQ-MELF, A | Tape & Reel (TR) | Active | Standard | 225 V | 200mA | 1 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 1 µA @ 250 V | - | Military | MIL-PRF-19500/118 | Surface Mount | D-5A | -65°C ~ 175°C |
|
|
JAN1N5196UR/TRSIGNAL OR COMPUTER DIODE |
2,654 |
|
Datasheet |
- | DO-213AA | Tape & Reel (TR) | Active | Standard | 225 V | 200mA | 1 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 1 µA @ 250 V | - | Military | MIL-PRF-19500/118 | Surface Mount | DO-213AA | -65°C ~ 175°C |
|
|
JAN1N5194UR/TRSIGNAL OR COMPUTER DIODE |
3,840 |
|
Datasheet |
- | DO-213AA | Tape & Reel (TR) | Active | Standard | 70 V | 200mA | 1 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 25 nA @ 70 V | - | Military | MIL-PRF-19500/118 | Surface Mount | DO-213AA | -55°C ~ 200°C |
|
|
JAN1N5195US/TRDIODE GP 180V 200MA DO213AA |
9,240 |
|
- |
- | DO-213AA | Tape & Reel (TR) | Active | Standard | 180 V | 200mA | 1 V @ 100 mA | Small Signal =< 200mA (Io), Any Speed | - | 5 µA @ 180 V | - | Military | MIL-PRF-19500/118 | Surface Mount | DO-213AA | -65°C ~ 175°C |
|
|
VS-VSKE56/04DIODE GP 400V 60A ADD-A-PAK |
8,680 |
|
Datasheet |
- | ADD-A-PAK (3) | Bulk | Active | Standard | 400 V | 60A | - | Standard Recovery >500ns, > 200mA (Io) | - | 10 mA @ 400 V | - | - | - | Chassis Mount | ADD-A-PAK® | -40°C ~ 150°C |
|
|
MF300U06F6-BPInterface |
5,679 |
|
Datasheet |
- | Module | Bulk | Active | Standard | 600 V | 300A | 1.15 V @ 300 A | Fast Recovery =< 500ns, > 200mA (Io) | 145 ns | 500 µA @ 600 V | - | - | - | Chassis Mount | F6 | -40°C ~ 150°C |
|
DSA75-16BDIODE AVAL 1.6KV 110A DO203AB |
8,357 |
|
Datasheet |
- | DO-203AB, DO-5, Stud | Bulk | Obsolete | Avalanche | 1600 V | 110A | 1.17 V @ 150 A | Standard Recovery >500ns, > 200mA (Io) | - | 6 mA @ 1600 V | - | - | - | Chassis, Stud Mount | DO-203AB | -40°C ~ 180°C |
|
DSAI75-16BDIODE AVAL 1.6KV 110A DO203AB |
6,750 |
|
Datasheet |
- | DO-203AB, DO-5, Stud | Bulk | Obsolete | Avalanche | 1600 V | 110A | 1.17 V @ 150 A | Standard Recovery >500ns, > 200mA (Io) | - | 6 mA @ 1600 V | - | - | - | Chassis, Stud Mount | DO-203AB | -40°C ~ 180°C |
|
|
VS-VSKE56/06DIODE GP 600V 60A ADD-A-PAK |
6,677 |
|
Datasheet |
- | ADD-A-PAK (3) | Bulk | Active | Standard | 600 V | 60A | - | Standard Recovery >500ns, > 200mA (Io) | - | 10 mA @ 600 V | - | - | - | Chassis Mount | ADD-A-PAK® | -40°C ~ 150°C |
.jpg)
|
183NQ080-1DIODE SCHOTTKY 80V 180A PRM1-1 |
3,138 |
|
Datasheet |
- | HALF-PAK | Bulk | Active | Schottky | 80 V | 180A | 950 mV @ 180 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 4.5 mA @ 80 V | 4150pF @ 5V, 1MHz | - | - | Chassis Mount | PRM1-1 (Half Pak Module) | -55°C ~ 175°C |
|
|
185NQ015-1DIODE SCHOTTKY 15V 180A PRM1-1 |
9,660 |
|
Datasheet |
- | HALF-PAK | Bulk | Active | Schottky | 15 V | 180A | 400 mV @ 180 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 60 mA @ 15 V | 12300pF @ 5V, 1MHz | - | - | Chassis Mount | PRM1-1 (Half Pak Module) | -55°C ~ 175°C |
|
|
186NQ200-1DIODE SCHOTTKY 200V 180A PRM1-1 |
4,886 |
|
Datasheet |
- | HALF-PAK | Bulk | Active | Schottky | 200 V | 180A | 1.12 V @ 180 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 4.5 mA @ 200 V | 2700pF @ 5V, 1MHz | - | - | Chassis Mount | PRM1-1 (Half Pak Module) | -55°C ~ 175°C |
|
|
189NQ135-1DIODE SCHOTTKY 135V 180A PRM1-1 |
9,450 |
|
Datasheet |
- | HALF-PAK | Bulk | Active | Schottky | 135 V | 180A | 1.07 V @ 180 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 4.5 mA @ 135 V | 4500pF @ 5V, 1MHz | - | - | Chassis Mount | PRM1-1 (Half Pak Module) | -55°C ~ 175°C |
|
|
189NQ135R-1DIODE SCHOTTKY 135V 180A PRM1-1 |
6,593 |
|
Datasheet |
- | HALF-PAK | Bulk | Active | Schottky | 135 V | 180A | 1.07 V @ 180 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 4.5 mA @ 135 V | 4500pF @ 5V, 1MHz | - | - | Chassis Mount | PRM1-1 (Half Pak Module) | -55°C ~ 175°C |
|
|
189NQ150-1DIODE SCHOTTKY 150V 180A PRM1-1 |
2,614 |
|
Datasheet |
- | HALF-PAK | Bulk | Active | Schottky | 150 V | 180A | 1.07 V @ 180 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 4.5 mA @ 150 V | 4500pF @ 5V, 1MHz | - | - | Chassis Mount | PRM1-1 (Half Pak Module) | -55°C ~ 175°C |
|
|
189NQ150R-1DIODE SCHOTTKY 150V 180A PRM1-1 |
7,292 |
|
Datasheet |
- | HALF-PAK | Bulk | Active | Schottky | 150 V | 180A | 1.07 V @ 180 A | Fast Recovery =< 500ns, > 200mA (Io) | - | 4.5 mA @ 150 V | 4500pF @ 5V, 1MHz | - | - | Chassis Mount | PRM1-1 (Half Pak Module) | -55°C ~ 175°C |
|
|
JANTXV1N6078DIODE GEN PURP 150V 1.3A E-PAK |
2,620 |
|
Datasheet |
- | E, Axial | Bulk | Active | Standard | 150 V | 1.3A | 1.76 V @ 18.8 A | Fast Recovery =< 500ns, > 200mA (Io) | 30 ns | 1 µA @ 150 V | - | Military | MIL-PRF-19500/503 | Through Hole | E-PAK | -65°C ~ 155°C |
|
|
JANS1N5807DIODE GEN PURP 50V 6A B AXIAL |
5,222 |
|
- |
- | B, Axial | Bulk | Active | Standard | 50 V | 6A | 875 mV @ 4 A | Fast Recovery =< 500ns, > 200mA (Io) | 30 ns | - | - | Military | MIL-PRF-19500/477 | Through Hole | B, Axial | -65°C ~ 175°C |
|
VS-T110HF80DIODE GEN PURP 800V 110A D-55 |
8,252 |
|
Datasheet |
- | D-55 T-Module | Bulk | Active | Standard | 800 V | 110A | - | Standard Recovery >500ns, > 200mA (Io) | - | 20 mA @ 800 V | - | - | - | Chassis Mount | D-55 | - |
|
|
GC05MPS33J-TR3300V 5A TO-263-7 SIC SCHOTTKY M |
7,595 |
|
Datasheet |
MPS™ | TO-263-8, D2PAK (7 Leads + Tab), TO-263CA | Tape & Reel (TR) | Discontinued at Digi-Key | SiC (Silicon Carbide) Schottky | 3300 V | 11A | 3 V @ 5 A | No Recovery Time > 500mA (Io) | 0 ns | 50 µA @ 3300 V | 337pF @ 1V, 1MHz | - | - | Surface Mount | TO-263-7 | -55°C ~ 175°C |
Single Diodes Electronic Components
Frequently Asked Questions
Q1: What products are included in Single Diodes?
This category includes related Single Diodes subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Single Diodes components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Single Diodes and other electronic components.
