Pressure Sensors, Transducers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Applications | Pressure Type | Operating Pressure | Output Type | Output | Accuracy | Voltage - Supply | Port Size | Port Style | Features | Termination Style | Maximum Pressure | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
0.3 PSI-GF-PRIME-MINISENSOR 0.3PSIG 0.18" .02V |
0 |
|
Datasheet |
ACPC | 4-SIP Module | Tube | Active | Board Mount | Vented Gauge | 0.3PSI (2.07kPa) | Wheatstone Bridge | 0 mV ~ 20 mV (12V) | ±0.25% | 16V | Male - 0.18" (4.57mm) Tube | Barbless | Temperature Compensated | PC Pin | 3PSI (20.68kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
0.3 PSI-D-PRIME-MINISENSOR 0.3PSID 0.17" .02V |
0 |
|
Datasheet |
ACPC | 4-SIP Module | Tube | Active | Board Mount | Differential | 0.3PSI (2.07kPa) | Wheatstone Bridge | 0 mV ~ 20 mV (12V) | ±0.25% | 16V | Male - 0.17" (4.34mm) Tube, Dual | Barbless | Temperature Compensated | PC Pin | 3PSI (20.68kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
10 INCH-G-PRIME-MINISENSOR GAUGE 10" 0.36PSIG .02V |
0 |
|
Datasheet |
ACPC | 4-SIP Module | Tube | Active | Board Mount | Vented Gauge | 0.36PSI (2.49kPa) | Wheatstone Bridge | 0 mV ~ 20 mV (12V) | ±0.25% | 16V | - | No Port | Temperature Compensated | PC Pin | 5PSI (34.47kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
10 INCH-GF-PRIME-MINISENSOR 0.36PSIG 0.18" .02V |
0 |
|
Datasheet |
ACPC | 4-SIP Module | Tube | Active | Board Mount | Vented Gauge | 0.36PSI (2.49kPa) | Wheatstone Bridge | 0 mV ~ 20 mV (12V) | ±0.25% | 16V | Male - 0.18" (4.57mm) Tube | Barbless | Temperature Compensated | PC Pin | 5PSI (34.47kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
10 INCH-D-PRIME-MINISENSOR 0.36PSID 0.17" .02V |
0 |
|
Datasheet |
ACPC | 4-SIP Module | Tube | Active | Board Mount | Differential | 0.36PSI (2.49kPa) | Wheatstone Bridge | 0 mV ~ 20 mV (12V) | ±0.25% | 16V | Male - 0.17" (4.34mm) Tube, Dual | Barbless | Temperature Compensated | PC Pin | 5PSI (34.47kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
1 PSI-G-PRIME-MINISENSOR 1PSIG .018V |
0 |
|
Datasheet |
ACPC | 4-SIP Module | Tube | Active | Board Mount | Vented Gauge | 1PSI (6.89kPa) | Wheatstone Bridge | 0 mV ~ 18 mV (12V) | ±0.25% | 16V | - | No Port | Temperature Compensated | PC Pin | 10PSI (68.95kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
1 PSI-GF-PRIME-MINISENSOR 1PSIG 0.18" .018V |
0 |
|
Datasheet |
ACPC | 4-SIP Module | Tube | Active | Board Mount | Vented Gauge | 1PSI (6.89kPa) | Wheatstone Bridge | 0 mV ~ 18 mV (12V) | ±0.25% | 16V | Male - 0.18" (4.57mm) Tube | Barbless | Temperature Compensated | PC Pin | 10PSI (68.95kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
DC010NGR5SENSOR 0.36PSIG 0.19" 6V |
0 |
|
Datasheet |
DC | 4-SIP Module | Bulk | Obsolete | Board Mount | Vented Gauge | 0.36PSI (2.49kPa) | Analog Voltage | 1 V ~ 6 V | ±0.25% | 5V | Male - 0.19" (4.83mm) Tube, Dual | Barbed | Temperature Compensated | - | 5.42PSI (37.38kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
DC010NGC4SENSOR 0.36PSIG 0.19" 4.25V |
0 |
|
Datasheet |
DC | 4-SIP Module | Bulk | Obsolete | Board Mount | Vented Gauge | 0.36PSI (2.49kPa) | Analog Voltage | 0.25 V ~ 4.25 V | ±0.25% | 5V | Male - 0.19" (4.83mm) Tube, Dual | Barbed | Temperature Compensated | - | 5.42PSI (37.38kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
DC010NDR4SENSOR 0.36PSID 0.19" 4.25V |
0 |
|
Datasheet |
DC | 4-SIP Module | Bulk | Obsolete | Board Mount | Differential | 0.36PSI (2.49kPa) | Analog Voltage | 0.25 V ~ 4.25 V | ±0.25% | 5V | Male - 0.19" (4.83mm) Tube, Dual | Barbed | Temperature Compensated | - | 5.42PSI (37.38kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
SDX005IND4SENSOR 0.18PSID 0.09" .02V |
0 |
|
- |
SDX IND | 6-DIP Module | Bulk | Obsolete | Board Mount | Differential | 0.18PSI (1.25kPa) | Wheatstone Bridge | 0 mV ~ 20 mV (12V) | ±1% | 20V | Male - 0.09" (2.3mm) Tube | Barbless | Temperature Compensated | PC Pin | 6.97PSI (48.09kPa) | -40°C ~ 85°C | - | - | Through Hole | - |
|
15 PSI-G-4V-PRIME-REFSENSOR 15PSIG 0.19" 4.25V |
0 |
|
Datasheet |
- | 4-SIP Module | Bulk | Obsolete | Board Mount | Vented Gauge | 15PSI (103.42kPa) | Analog Voltage | 0.25 V ~ 4.25 V | ±0.25% | 5.5V ~ 16V | Male - 0.19" (4.83mm) Tube | Barbless | Amplified Output, Temperature Compensated | PC Pin | 45PSI (310.26kPa) | -40°C ~ 125°C | - | - | Through Hole | - |
|
|
5 PSI-D-4V-PRIME-REFSENSOR 5PSID 0.19" 4.25V |
0 |
|
Datasheet |
- | 4-SIP Module | Bulk | Obsolete | Board Mount | Differential | ±5PSI (±34.47kPa) | Analog Voltage | 0.25 V ~ 4.25 V | ±0.25% | 5.5V ~ 16V | Male - 0.19" (4.83mm) Tube, Dual | Barbless | Amplified Output, Temperature Compensated | PC Pin | ±15PSI (±103.42kPa) | -40°C ~ 125°C | - | - | Through Hole | - |
|
|
5 PSI-G-4V-PRIME-REFSENSOR 5PSIG 0.19" 4.25V |
0 |
|
Datasheet |
- | 4-SIP Module | Bulk | Obsolete | Board Mount | Vented Gauge | 5PSI (34.47kPa) | Analog Voltage | 0.25 V ~ 4.25 V | ±0.25% | 5.5V ~ 16V | Male - 0.19" (4.83mm) Tube | Barbless | Amplified Output, Temperature Compensated | PC Pin | 15PSI (103.42kPa) | -40°C ~ 125°C | - | - | Through Hole | - |
|
|
20 INCH-G-4V-REFSENSOR 0.72PSIG 0.19" 4.25V |
0 |
|
Datasheet |
- | 4-SIP Module | Bulk | Obsolete | Board Mount | Vented Gauge | 0.72PSI (4.98kPa) | Analog Voltage | 0.25 V ~ 4.25 V | ±0.25% | 5.5V ~ 16V | Male - 0.19" (4.83mm) Tube | Barbless | Amplified Output, Temperature Compensated | PC Pin | 10.84PSI (74.75kPa) | -25°C ~ 85°C | - | - | Through Hole | - |
|
|
P-3000S-501D-10SENSOR 7.11PSID |
0 |
|
Datasheet |
P-3000S | 5-DIP Module, Dual Ports, Opposite Sides | Bulk | Active | Board Mount | Differential | 7.11PSI (49kPa) | Analog Voltage | - | ±0.1% | - | - | Barbless | Temperature Compensated | PC Pin | 14.23PSI (98.1kPa) | -20°C ~ 100°C | - | - | Through Hole | - |
|
ASDXAVX015PGAA5SENSOR 15PSIG 0.09" 4.5V |
0 |
|
Datasheet |
ASDX | 8-DIP Module | Bulk | Active | Board Mount | Vented Gauge | 15PSI (103.42kPa) | Analog Voltage | 0.5 V ~ 4.5 V | ±2% | 4.75V ~ 5.25V | Male - 0.09" (2.31mm) Tube | Barbless | Temperature Compensated | PC Pin | 30PSI (206.84kPa) | -20°C ~ 105°C | - | - | Through Hole | - |
|
ASDXRRX100PGAA5SENSOR 100PSIG 0.09" 4.5V |
0 |
|
- |
ASDX | 8-DIP Module | Bulk | Active | Board Mount | Vented Gauge | 100PSI (689.48kPa) | Analog Voltage | 0.5 V ~ 4.5 V | ±2% | 4.75V ~ 5.25V | Male - 0.09" (2.31mm) Tube, Dual | Barbless | Temperature Compensated | PC Pin | 200PSI (1378.95kPa) | -20°C ~ 105°C | - | - | Through Hole | - |
|
|
M5241-000005-06KPGTRANSDUCER 1-5VDC 6000PSI |
0 |
|
- |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
M5241-020005-05KPGPRESSURE TRANSDUCER |
0 |
|
Datasheet |
* | - | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Pressure Sensors, Transducers Electronic Components
Explore Pressure Sensors, Transducers electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
