Power Relays, Over 2 Amps
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Mounting Type | Coil Voltage | Contact Form | Contact Rating (Current) | Switching Voltage | Load - Max Switching | Coil Current | Coil Type | Features | Termination Style | Seal Rating | Coil Insulation | Must Operate Voltage | Must Release Voltage | Operate Time | Release Time | Operating Temperature | Contact Material | Relay Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RY4V-UDC12V4PDT PCB RELAY |
0 |
|
- |
RY | Bulk | Obsolete | Socketable | 12VDC | 4PDT (4 Form C) | 5 A | 240VAC, 30VDC - Max | 1200VA, 150W | 75 mA | Non Latching | - | Plug In | - | - | 9.6 VDC | 1.2 VDC | 20 ms | 20 ms | -25°C ~ 55°C | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
2575990000RELAY GEN PURPOSE DPDT 10A 115V |
0 |
|
Datasheet |
DRM | Bulk | Active | DIN Rail | 115VAC | DPDT (2 Form C) | 10 A | 250VAC - Max | 2500VA | 288 mA | Non Latching | Lighted Indicator, Socket Included | Spring Terminal | - | - | 92 VAC | 34.5 VAC | 20 ms | 20 ms | -40°C ~ 55°C | Silver Nickel (AgNi), Gold (Au) | General Purpose | - | - |
|
|
276XAXH-24DPRINTED CIRCUIT BOARD RELAY |
0 |
|
Datasheet |
- | Box | Active | Through Hole | 24VDC | SPDT (1 Form C) | 10 A | 240VAC, 30VDC - Max | - | 8.3 mA | Non Latching | - | PC Pin | Sealed - Fully | Class E | 19.2 VDC | 2.4 VDC | 10 ms | - | -40°C ~ 70°C | Silver (Ag), Gold (Au) | General Purpose | - | - |
|
|
J1672AF24VDCZDRELAY GEN PURPOSE DPST |
0 |
|
Datasheet |
J167 | Tray | Active | Chassis Mount | 24VDC | DPST-NO (2 Form A) | 30 A | 277VAC, 30VDC - Max | 5500VA | 79.2 mA | Non Latching | Lighted Indicator | Screw Terminal | - | Class F | 16.8 VDC | 2.4 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Tin Oxide Indium Oxide (AgSnOInO) | General Purpose | - | - |
|
|
J1672AF240VACZDRELAY GEN PURPOSE DPST |
0 |
|
Datasheet |
J167 | Tray | Active | Chassis Mount | 240VAC | DPST-NO (2 Form A) | 30 A | 277VAC, 30VDC - Max | 5500VA | 11.4 mA | Non Latching | Lighted Indicator | Screw Terminal | - | Class F | 168 VAC | 24 VAC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Tin Oxide Indium Oxide (AgSnOInO) | General Purpose | - | - |
|
|
J1671AF110VDCZDTRELAY GEN PURPOSE SPST |
0 |
|
Datasheet |
J167 | Tray | Active | Chassis Mount | 110VDC | SPST-NO (1 Form A) | 30 A | 277VAC, 30VDC - Max | 6600VA | 17.3 mA | Non Latching | Lighted Indicator, Test Button | Screw Terminal | - | Class F | 77 VDC | 11 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Tin Oxide Indium Oxide (AgSnOInO) | General Purpose | - | - |
|
|
J1671AF220VDCZDTRELAY GEN PURPOSE SPST |
0 |
|
Datasheet |
J167 | Tray | Active | Chassis Mount | 220VDC | SPST-NO (1 Form A) | 30 A | 277VAC, 30VDC - Max | 6600VA | 8.6 mA | Non Latching | Lighted Indicator, Test Button | Screw Terminal | - | Class F | 154 VDC | 22 VDC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Tin Oxide Indium Oxide (AgSnOInO) | General Purpose | - | - |
|
|
J1671AF12VACZDTRELAY GEN PURPOSE SPST |
0 |
|
Datasheet |
J167 | Tray | Active | Chassis Mount | 12VAC | SPST-NO (1 Form A) | 30 A | 277VAC, 30VDC - Max | 6600VA | 218.2 mA | Non Latching | Lighted Indicator, Test Button | Screw Terminal | - | Class F | 8.4 VAC | 1.2 VAC | 30 ms | 30 ms | -40°C ~ 85°C | Silver Tin Oxide Indium Oxide (AgSnOInO) | General Purpose | - | - |
, G2R-1-S-DC12S, G2R-1-S-DC24S, G2R-1-S-DC48(S).jpg)
|
G2R-1-S DC5(S)RELAY GEN PURPOSE SPDT 10A 5V |
0 |
|
Datasheet |
G2RS | Bulk | Obsolete | Socketable | 5VDC | SPDT (1 Form C) | 10 A | 440VAC, 125VDC - Max | 4400VA, 1250W | 106 mA | Non Latching | - | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 3.5 VDC | 0.75 VDC | 15 ms | 10 ms | -40°C ~ 70°C | - | General Purpose | - | - |
|
|
MY2F-AC220/240RELAY GEN PURPOSE DPDT 5A 240V |
0 |
|
Datasheet |
MY | Bulk | Active | Chassis Mount | 240VAC | DPDT (2 Form C) | 5 A | 250VAC, 125VDC - Max | 1250VA, 625W | 12.8 mA | Non Latching | - | Solder Lug | - | - | 192 VAC | 72 VAC | 20 ms | 20 ms | -55°C ~ 70°C | Silver (Ag) | General Purpose | - | - |
|
8869980000RELAY GEN PURPOSE SPDT 16A 110V |
0 |
|
Datasheet |
RCI | Bulk | Obsolete | Through Hole | 110VDC | SPDT (1 Form C) | 16 A | 250VAC - Max | 4000VA | 4.1 mA | Non Latching | Test Button | PC Pin | - | - | 77 VDC | 11 VDC | 8 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
G6B-1177P-FD-ND-USDC24RELAY GEN PURPOSE SPST 8A 24V |
0 |
|
Datasheet |
G6B | Bulk | Active | Through Hole | 24VDC | SPST-NO (1 Form A) | 8 A | 380VAC, 125VDC - Max | 3040VA, 1000W | 8.3 mA | Non Latching | - | PC Pin | Sealed - Flux Protection | - | 16.8 VDC | 2.4 VDC | 10 ms | 10 ms | -25°C ~ 70°C | Silver Indium Tin (AgInSn) | General Purpose | - | - |
|
|
8530700000RELAY GEN PURPOSE DPDT 10A 24V |
0 |
|
- |
PRZ | Bulk | Obsolete | DIN Rail | 24VDC | DPDT (2 Form C) | 10 A | 250VAC - Max | 2500VA | 16.7 mA | Non Latching | Lighted Indicator, Socket Included | Spring Terminal | - | - | 16.8 VDC | 2.4 VDC | - | - | -40°C ~ 50°C | - | General Purpose | - | - |
|
|
55.32.9.125.0040RELAY GEN PURPOSE DPDT 10A 125V |
0 |
|
Datasheet |
55 | Bulk | Active | Socketable | 125VDC | DPDT (2 Form C) | 10 A | 400VAC - Max | 4000VA | 7.2 mA | Non Latching | Mechanical Indicator, Test Button | Plug In | - | - | 100 VDC | 25 VDC | 10 ms | 5 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
56.32.8.120.0030RELAY GEN PURPOSE DPDT 12A 120V |
0 |
|
Datasheet |
56 | Bulk | Active | Socketable | 120VAC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 12 mA | Non Latching | Lighted Indicator | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 96 VAC | 24 VAC | 9 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
55.32.8.110.0050RELAY GEN PURPOSE DPDT 10A 110V |
0 |
|
Datasheet |
55 | Bulk | Active | Socketable | 110VAC | DPDT (2 Form C) | 10 A | 400VAC - Max | 4000VA | 12.5 mA | Non Latching | Lighted Indicator, Test Button | Plug In | - | - | 88 VAC | 22 VAC | 10 ms | 5 ms | -40°C ~ 85°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
56.32.9.024.0094RELAY GEN PURPOSE DPDT 12A 24V |
0 |
|
Datasheet |
56 | Bulk | Active | Socketable | 24VDC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 40 mA | Non Latching | Diode, Lighted Indicator, Mechanical Indicator, Test Button | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 19.2 VDC | 4.8 VDC | 9 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
56.32.9.024.0090RELAY GEN PURPOSE DPDT 12A 24V |
0 |
|
Datasheet |
56 | Bulk | Active | Socketable | 24VDC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 40 mA | Non Latching | Diode, Lighted Indicator, Test Button | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 19.2 VDC | 4.8 VDC | 9 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
56.32.9.012.0070RELAY GEN PURPOSE DPDT 12A 12V |
0 |
|
Datasheet |
56 | Bulk | Active | Socketable | 12VDC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 86 mA | Non Latching | Lighted Indicator, Test Button | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 9.6 VDC | 2.4 VDC | 9 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
|
|
56.32.9.024.0060RELAY GEN PURPOSE DPDT 12A 24V |
0 |
|
Datasheet |
56 | Bulk | Active | Socketable | 24VDC | DPDT (2 Form C) | 12 A | 400VAC - Max | 4800VA | 40 mA | Non Latching | Lighted Indicator | Plug In, Quick Connect - 0.187" (4.7mm) | - | - | 19.2 VDC | 4.8 VDC | 9 ms | 6 ms | -40°C ~ 70°C | Silver Nickel (AgNi) | General Purpose | - | - |
Power Relays, Over 2 Amps Electronic Components
Explore Power Relays, Over 2 Amps electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
Frequently Asked Questions
Q1: What products are included in Power Relays, Over 2 Amps?
This category includes related Power Relays, Over 2 Amps subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Power Relays, Over 2 Amps components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Power Relays, Over 2 Amps and other electronic components.
