Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Output Configuration | Output Type | Number of Regulators | Voltage - Input (Max) | Voltage - Output (Min/Fixed) | Voltage - Output (Max) | Voltage Dropout (Max) | Current - Output | Current - Quiescent (Iq) | Current - Supply (Max) | PSRR | Control Features | Protection Features | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
LM2936QDT-3.0/NOPBIC REG LINEAR 3V 50MA TO252-3 |
0 |
|
Datasheet |
- | TO-252-3, DPAK (2 Leads + Tab), SC-63 | Bulk | Active | Positive | Fixed | 1 | 40V | 3V | - | 0.4V @ 50mA | 50mA | 15 µA | 2.5 mA | 60dB (120Hz) | - | Over Temperature, Reverse Polarity, Short Circuit | -40°C ~ 125°C (TJ) | Automotive | AEC-Q100 | Surface Mount | TO-252-3 |
|
LM3480IM3-12IC REG LINEAR 12V 100MA SOT23-3 |
1,715 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 30V | 12V | - | 1.2V @ 100mA | 100mA | 2 mA | - | - | - | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | SOT-23-3 |
|
|
LM3480IM3-3.3IC REG LINEAR 3.3V 100MA SOT23-3 |
5,984 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 30V | 3.3V | - | 1.2V @ 100mA | 100mA | 2 mA | - | - | - | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | SOT-23-3 |
|
TPS73230DBVTIC REG LINEAR 3V 250MA SOT23-5 |
5,530 |
|
Datasheet |
TPS732xx | SC-74A, SOT-753 | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 5.5V | 3V | - | 0.15V @ 250mA | 250mA | 550 µA | 950 µA | 58dB ~ 37dB (100Hz ~ 10kHz) | Enable | Over Current, Over Temperature, Short Circuit, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | SOT-23-5 |
|
ADP1706ARDZ-1.05R7IC REG LDO 1.05V 1A 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | Cut Tape (CT) | Obsolete | Positive | Fixed | 1 | 5.5V | 1.05V | - | 0.6V @ 1A | 1A | 390 µA | 1.55 mA | - | Enable, Soft Start | Over Current, Over Temperature | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-SOIC-EP |
|
CS8151YTVA7IC REG LINEAR 5V 100MA TO220-7 |
4,800 |
|
Datasheet |
- | TO-220-7 Formed Leads | Tube | Obsolete | Positive | Fixed | 1 | 26V | 5V | - | 0.6V @ 100mA | 100mA | - | - | 75dB (120Hz) | Reset, Wake-Up, Watchdog | Over Temperature, Over Voltage, Short Circuit | -40°C ~ 125°C | - | - | Through Hole | TO-220-7 |
|
|
LM3480IM3-5.0IC REG LINEAR 5V 100MA SOT23-3 |
4,513 |
|
Datasheet |
- | TO-236-3, SC-59, SOT-23-3 | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 30V | 5V | - | 1.2V @ 100mA | 100mA | 2 mA | - | - | - | Over Current, Over Temperature | -40°C ~ 125°C | - | - | Surface Mount | SOT-23-3 |
|
LX8211-25ISEIC REG LINEAR 2.5V 150MA SOT23-5 |
3,701 |
|
Datasheet |
- | SC-74A, SOT-753 | Bulk | Active | Positive | Fixed | 1 | 6V | 2.5V | - | 0.4V @ 150mA | 150mA | 220 µA | - | 50dB (120Hz) | Enable | Over Temperature, Short Circuit | -40°C ~ 125°C | - | - | Surface Mount | SOT-23-5 |
|
|
ADP1706ARDZ-0.95R7IC REG LDO 0.95V 1A 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | Cut Tape (CT) | Obsolete | Positive | Fixed | 1 | 5.5V | 0.95V | - | 0.6V @ 1A | 1A | 390 µA | 1.55 mA | - | Enable, Soft Start | Over Current, Over Temperature | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-SOIC-EP |
|
|
ADP1706ARDZ-0.85R7IC REG LDO 0.85V 1A 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) Exposed Pad | Cut Tape (CT) | Obsolete | Positive | Fixed | 1 | 5.5V | 0.85V | - | 0.6V @ 1A | 1A | 390 µA | 1.55 mA | - | Enable, Soft Start | Over Current, Over Temperature | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-SOIC-EP |
|
MIC29153BTIC REG LINEAR HIGH CURRENT LDO |
1,905 |
|
Datasheet |
- | TO-220-5 | Bulk | Active | Positive | Adjustable | 1 | 26V | 1.25V | 25V | 0.6V @ 1.5A | 1.5A | 20 mA | - | - | Error Flag | Load Dump, Over Current, Over Temperature, Reverse Polarity, Transient Voltage | -40°C ~ 125°C (TJ) | - | - | Through Hole | TO-220-5 |
|
|
LX8211-30ISEIC REG LINEAR 3V 150MA SOT23-5 |
1,873 |
|
Datasheet |
- | SC-74A, SOT-753 | Tube | Obsolete | Positive | Fixed | 1 | 6V | 3V | - | 0.4V @ 150mA | 150mA | 220 µA | - | 50dB (120Hz) | Enable | Over Temperature, Short Circuit | -40°C ~ 125°C | - | - | Surface Mount | SOT-23-5 |
|
LM337LZIC REG LIN ADJ NEGATIVE STND REG |
1,726 |
|
Datasheet |
- | TO-226-3, TO-92-3 (TO-226AA) | Bulk | Active | Negative | Adjustable | 1 | -40V | -1.2V | -37V | - | 100mA | 5 mA | - | 80dB ~ 65dB (120Hz) | - | Over Current, Over Temperature, Short Circuit | -25°C ~ 125°C (TJ) | - | - | Through Hole | TO-92-3 |
|
|
TPS73218DBVTIC REG LINEAR 1.8V 250MA SOT23-5 |
1,414 |
|
Datasheet |
TPS732xx | SC-74A, SOT-753 | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 5.5V | 1.8V | - | 0.15V @ 250mA | 250mA | 550 µA | 950 µA | 58dB ~ 37dB (100Hz ~ 10kHz) | Enable | Over Current, Over Temperature, Short Circuit, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | SOT-23-5 |
|
CS8151YTHA7GIC REG LINEAR 5V 100MA TO220-7 |
1,250 |
|
Datasheet |
- | TO-220-7 Formed Leads | Tube | Obsolete | Positive | Fixed | 1 | 26V | 5V | - | 0.6V @ 100mA | 100mA | - | - | 75dB (120Hz) | Reset, Wake-Up, Watchdog | Over Temperature, Over Voltage, Short Circuit | -40°C ~ 125°C | - | - | Through Hole | TO-220-7 |
|
BA78M06CP-E2IC REG LINEAR 6V 500MA TO220CP-3 |
347 |
|
Datasheet |
- | TO-220-3 Cropped Leads | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 21V | 6V | - | 2V @ 500mA (Typ) | 500mA | 6 mA | 800 µA | 74dB (120Hz) | - | Over Current, Over Temperature | -40°C ~ 85°C | - | - | Through Hole | TO-220CP-3 |
|
|
BA78M20CP-E2IC REG LIN 20V 500MA TO220CP-3 |
143 |
|
Datasheet |
- | TO-220-3 Cropped Leads | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 33V | 20V | - | 2V @ 500mA (Typ) | 500mA | 6 mA | 800 µA | 58dB (120Hz) | - | Over Current, Over Temperature | -40°C ~ 85°C | - | - | Through Hole | TO-220CP-3 |
|
CS5253B-8GDPR5IC REG LINEAR 2.5V 3A D2PAK-5 |
0 |
|
Datasheet |
- | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 13V | 2.5V | - | 1.3V @ 3A | 3A | 10 mA | - | 80dB (120Hz) | - | Over Current, Over Temperature, Short Circuit | 0°C ~ 70°C | - | - | Surface Mount | D2PAK-5 |
|
TPS77518DRIC REG LINEAR 1.8V 500MA 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 1.8V | - | - | 500mA | 125 µA | - | 60dB (100Hz) | Enable, Reset | Over Current, Over Temperature, Reverse Polarity | -40°C ~ 125°C | - | - | Surface Mount | 8-SOIC |
|
|
MIC29301-3.3BTIC REG LINEAR 3.3V 3A TO220-5 |
11,354 |
|
Datasheet |
- | TO-220-5 | Bulk | Obsolete | Positive | Fixed | 1 | 26V | 3.3V | - | 0.6V @ 3A | 3A | - | - | - | Enable | Over Current, Over Temperature, Reverse Polarity, Transient Voltage | -40°C ~ 125°C | - | - | Through Hole | TO-220-5 |
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Electronic Components
Frequently Asked Questions
Q1: What products are included in Voltage Regulators - Linear, Low Drop Out (LDO) Regulators?
This category includes related Voltage Regulators - Linear, Low Drop Out (LDO) Regulators subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Voltage Regulators - Linear, Low Drop Out (LDO) Regulators components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Voltage Regulators - Linear, Low Drop Out (LDO) Regulators and other electronic components.
