Voltage Regulators - Linear, Low Drop Out (LDO) Regulators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Output Configuration | Output Type | Number of Regulators | Voltage - Input (Max) | Voltage - Output (Min/Fixed) | Voltage - Output (Max) | Voltage Dropout (Max) | Current - Output | Current - Quiescent (Iq) | Current - Supply (Max) | PSRR | Control Features | Protection Features | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
S-19244F33A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 3.3V | - | 0.38V @ 1A | 1A | 150 µA | - | 50dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19244B50A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 5V | - | 0.38V @ 1A | 1A | 150 µA | - | 50dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19244C33A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 3.3V | - | 0.38V @ 1A | 1A | 150 µA | - | 50dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19244D33A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 3.3V | - | 0.38V @ 1A | 1A | 150 µA | - | 50dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19244H12A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 1.2V | - | - | 1A | 150 µA | - | 60dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19244C50A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 5V | - | 0.38V @ 1A | 1A | 150 µA | - | 50dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19244H18A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 1.8V | - | - | 1A | 150 µA | - | 55dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19243C33A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19243xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 3.3V | - | 0.09V @ 200mA | 500mA | 150 µA | - | 50dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19243H18A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19243xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 1.8V | - | 1V @ 200mA | 500mA | 150 µA | - | 55dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19243C12A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19243xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 1.2V | - | 1.3V @ 200mA | 500mA | 150 µA | - | 60dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
|
S-19244B33A-A8T1ULINEAR IC |
0 |
|
Datasheet |
S-19244xxxA | 8-SMD, Flat Leads Exposed Pad | Tape & Reel (TR) | Active | Positive | Fixed | 1 | 10V | 3.3V | - | 0.38V @ 1A | 1A | 150 µA | - | 50dB (1kHz) | Enable, Soft Start | Over Current, Over Temperature, Short Circuit | -40°C ~ 125°C (TA) | Automotive | AEC-Q100 | Surface Mount | HSNT-8-A |
|
BA00BC0WF-E2IC REG LINEAR POS ADJ 500MA 8SOP |
0 |
|
Datasheet |
- | 8-SOIC (0.173", 4.40mm Width) | Tape & Reel (TR) | Not For New Designs | Positive | Adjustable | 1 | 16V | 1.5V | 12V | 0.5V @ 500mA | 500mA | 130 µA | - | 55dB (120Hz) | - | Over Current, Over Temperature | -40°C ~ 105°C | - | - | Surface Mount | 8-SOP |
|
TPS7B8633BQDDARQ1PROTOTYPE |
0 |
|
- |
- | 8-PowerSOIC (0.154", 3.90mm Width) | Bulk | Active | Positive | Fixed | 1 | 40V | 3.3V | - | 0.535V @ 500mA | 500mA | 26 µA | - | 70dB (1kHz) | Delay, Enable, Power Good | Over Temperature, Under Voltage Lockout (UVLO) | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | 8-SO PowerPad |
|
|
TPS7B8650BQDDARQ1PROTOTYPE |
0 |
|
- |
- | 8-PowerSOIC (0.154", 3.90mm Width) | Bulk | Active | Positive | Fixed | 1 | 40V | 5V | - | 0.535V @ 500mA | 500mA | 26 µA | - | 70dB (1kHz) | Delay, Enable, Power Good | Over Temperature, Under Voltage Lockout (UVLO) | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | 8-SO PowerPad |
|
NCV4279A50D2GIC REG LINEAR 5V 150MA 14SOIC |
0 |
|
Datasheet |
- | 14-SOIC (0.154", 3.90mm Width) | Tube | Obsolete | Positive | Fixed | 1 | 45V | 5V | - | 0.5V @ 100mA | 150mA | 250 µA | 3 mA | - | Reset | Over Temperature, Reverse Polarity, Short Circuit | -40°C ~ 150°C | Automotive | AEC-Q100 | Surface Mount | 14-SOIC |
|
SI-3033ZD-TLIC REG LINEAR 3.3V 3A TO263-5 |
0 |
|
Datasheet |
- | TO-263-6, D2PAK (5 Leads + Tab), TO-263BA | Tape & Reel (TR) | Obsolete | Positive | Fixed | 1 | 6V | 3.3V | - | 0.6V @ 3A | 3A | 1.5 mA | - | 60dB (100Hz ~ 120Hz) | Enable | Over Current, Over Temperature | -20°C ~ 100°C | - | - | Surface Mount | TO-263-5 |
|
IRU1207-18CSIC REG LINEAR 1.8V 1A 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Obsolete | Positive | Fixed | 1 | 12V | 1.8V | - | 0.65V @ 1A | 1A | 3 mA | 50 mA | - | Enable | Over Current, Over Temperature | 0°C ~ 125°C | - | - | Surface Mount | 8-SOIC |
|
|
IRU1207-25CSIC REG LINEAR 2.5V 1A 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Obsolete | Positive | Fixed | 1 | 12V | 2.5V | - | 0.65V @ 1A | 1A | 3 mA | 50 mA | - | Enable | Over Current, Over Temperature | 0°C ~ 125°C | - | - | Surface Mount | 8-SOIC |
|
|
IRU1207-33CSIC REG LINEAR 3.3V 1A 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Obsolete | Positive | Fixed | 1 | 12V | 3.3V | - | 0.65V @ 1A | 1A | 3 mA | 50 mA | - | Enable | Over Current, Over Temperature | 0°C ~ 125°C | - | - | Surface Mount | 8-SOIC |
|
|
IRU1208CSIC REG LINEAR POS ADJ 1A 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tube | Obsolete | Positive | Adjustable | 1 | 12V | 1.24V | 11.35V | 0.65V @ 1A | 1A | 3 mA | 50 mA | - | - | Over Current, Over Temperature | 0°C ~ 125°C | - | - | Surface Mount | 8-SOIC |
Voltage Regulators - Linear, Low Drop Out (LDO) Regulators Electronic Components
Explore Voltage Regulators - Linear, Low Drop Out (LDO) Regulators electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
Frequently Asked Questions
Q1: What products are included in Voltage Regulators - Linear, Low Drop Out (LDO) Regulators?
This category includes related Voltage Regulators - Linear, Low Drop Out (LDO) Regulators subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Voltage Regulators - Linear, Low Drop Out (LDO) Regulators components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Voltage Regulators - Linear, Low Drop Out (LDO) Regulators and other electronic components.
