Power Distribution Switches, Load Drivers
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Switch Type | Number of Outputs | Ratio - Input:Output | Output Configuration | Output Type | Interface | Voltage - Load | Voltage - Supply (Vcc/Vdd) | Current - Output (Max) | Rds On (Typ) | Input Type | Features | Fault Protection | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
TCKE912NA,RFEFUSE IC WSON8, 4A/23V FAST PROT |
2,970 |
|
Datasheet |
8-WFDFN Exposed Pad | TCKE9 | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 2.7V ~ 23V | Not Required | 4A | 34mOhm | Non-Inverting | Load Discharge, Slew Rate Controlled, Status Flag | Current Limiting (Adjustable), Over Temperature, Over Voltage, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-WSON (2x2) |
|
|
TCKE912NL,RFEFUSE IC WSON8, 4A/23V FAST PROT |
2,935 |
|
Datasheet |
8-WFDFN Exposed Pad | TCKE9 | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 2.7V ~ 23V | Not Required | 4A | 34mOhm | Non-Inverting | Load Discharge, Slew Rate Controlled, Status Flag | Current Limiting (Adjustable), Over Temperature, Over Voltage, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-WSON (2x2) |
|
|
TCKE905ANA,RFEFUSE IC 4A/23V FAST PROTECTION |
2,906 |
|
Datasheet |
8-WFDFN Exposed Pad | TCKE9 | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 2.7V ~ 23V | Not Required | 4A | 34mOhm | Non-Inverting | Slew Rate Controlled, Status Flag | Current Limiting (Adjustable), Over Temperature, Over Voltage, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-WSON (2x2) |
|
|
TCKE903NL,RFEFUSE IC , 4A/23V FAST PROTECTIO |
2,391 |
|
Datasheet |
8-WFDFN Exposed Pad | TCKE9 | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 2.7V ~ 23V | Not Required | 4A | 34mOhm | Non-Inverting | Slew Rate Controlled, Status Flag | Current Limiting (Adjustable), Over Temperature, Over Voltage, Short Circuit, UVLO | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 8-WSON (2x2) |
|
BD2224G-LBTRIC PWR SWITCH N-CHAN 1:1 5SSOP |
3,000 |
|
Datasheet |
SC-74A, SOT-753 | - | Tape & Reel (TR) | Active | USB Switch | 1 | 1:1 | High Side | N-Channel | On/Off | 2.7V ~ 5.5V | Not Required | 550mA | 150mOhm | Non-Inverting | Slew Rate Controlled, Status Flag | Current Limiting (Fixed), Over Temperature, UVLO | -40°C ~ 85°C (TA) | - | - | Surface Mount | 5-SSOP |
|
MP5014AGJ-ZIC PWR SWTCH N-CHAN 1:1 TSOT23-8 |
2,945 |
|
Datasheet |
SOT-23-8 Thin, TSOT-23-8 | - | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 10V ~ 13.8V | Not Required | 5A | 36mOhm | - | Slew Rate Controlled | Current Limiting (Adjustable), Over Temperature, Over Voltage, UVLO | -40°C ~ 125°C (TJ) | - | - | Surface Mount | TSOT-23-8 |
|
|
BTS70802EPZXUMA1PROFET PG-TSDSO-14 |
2,400 |
|
Datasheet |
14-SOIC (0.154", 3.90mm Width) Exposed Pad | PROFET® | Tape & Reel (TR) | Active | General Purpose | 2 | 1:1 | High Side | N-Channel | On/Off | 6V ~ 18V | Not Required | 3A | 20.9mOhm | Non-Inverting | Slew Rate Controlled | Over Current, Over Temperature, Over Voltage, Short Circuit | -40°C ~ 175°C (TJ) | Automotive | AEC-Q100 | Surface Mount | PG-TDSO-14-11 |
|
|
NLPS22990MN1TAGIC PWR SWITCH N-CHAN 1:1 10WDFN |
2,685 |
|
Datasheet |
10-PowerWFDFN | - | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 0.6V ~ 5.5V | Not Required | 10A | 3.9mOhm | Inverting | Load Discharge, Power Good, Slew Rate Controlled | - | -40°C ~ 105°C (TA) | - | - | Surface Mount | 10-WDFN (3x2) |
|
|
BTS70302EPGXUMA1PROFET |
2,889 |
|
Datasheet |
14-TSSOP (0.154", 3.90mm Width) Exposed Pad | PROFET® | Tape & Reel (TR) | Active | Relay, Solenoid Driver | 2 | 1:1 | High Side | N-Channel | Logic | 3.1V ~ 18V | 3.1V ~ 18V | 4.5A | 13.5mOhm | Non-Inverting | Load Discharge, Slew Rate Controlled | Current Limiting (Adjustable), Open Load Detect, Over Temperature, Over Voltage, Reverse Battery, Short Circuit, UVLO | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | PG-TSDSO-14 |
|
BTS40K21ENCXUMA1IC PWR SWITCH N-CHANNEL 1:1 8DSO |
2,169 |
|
Datasheet |
- | PROFET® | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 5V ~ 36V | Not Required | 1.5A | 200mOhm | - | - | Current Limiting, Open Load Detect, Over Temperature, Over Voltage, UVLO | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | - | - |
|
|
NCV8415DTRKGSELF-PROTECTED LOW SIDE DRIVER W |
17,464 |
|
Datasheet |
TO-252-3, DPAK (2 Leads + Tab), SC-63 | - | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | Low Side | N-Channel | - | 42V | Not Required | 7A | 80mOhm | Non-Inverting | Auto Restart, Slew Rate Controlled | Current Limiting (Fixed), Over Temperature, Over Voltage, Short Circuit | -40°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | DPAK |
|
TPS2067DRIC PWR SWTCH N-CH 1:2/1:1 16SOIC |
2,460 |
|
Datasheet |
16-SOIC (0.154", 3.90mm Width) | - | Tape & Reel (TR) | Active | General Purpose | 3 | 1:2, 1:1 | High Side | N-Channel | On/Off | 2.7V ~ 5.5V | Not Required | 1A | 70mOhm | Non-Inverting | Status Flag | Current Limiting (Fixed), Over Temperature, UVLO | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 16-SOIC |
|
|
KTS1673BEGAE-TAVBUS CURRENT SINK PROTECTION |
3,000 |
|
Datasheet |
12-UFBGA, WLCSP | - | Tape & Reel (TR) | Active | USB Switch | 1 | 1:1 | High Side | N-Channel | On/Off | 3V ~ 24V | 3V ~ 24V | 5A | 22mOhm | Non-Inverting | Auto Restart, Power Good, Slew Rate Controlled | Current Limiting (Adjustable), Over Temperature, Over Voltage, Reverse Current, Short Circuit, UVLO | -40°C ~ 85°C | - | - | Surface Mount | 12-WLCSP (2.18x1.64) |
|
ZXMS6005DN8-13IC PWR DRIVER N-CHAN 1:1 8SOIC |
4,712 |
|
Datasheet |
8-SOIC (0.154", 3.90mm Width) | INTELLIFET® | Tape & Reel (TR) | Active | General Purpose | 2 | 1:1 | Low Side | N-Channel | On/Off | 60V (Max) | 3.3V, 5V | 1.8A | 150mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Over Temperature, Over Voltage | -40°C ~ 125°C (TA) | - | - | Surface Mount | 8-SOIC |
|
|
BTS70081EPZXUMA1PROFET PG-TSDSO-14 |
5,965 |
|
Datasheet |
14-SOIC (0.154", 3.90mm Width) Exposed Pad | PROFET® | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 6V ~ 18V | Not Required | 10A | 9mOhm | Non-Inverting | Slew Rate Controlled | Over Current, Over Temperature, Over Voltage, Short Circuit | -40°C ~ 175°C (TJ) | Automotive | AEC-Q100 | Surface Mount | PG-TDSO-14-11 |
|
AP2311MPG-13IC PWR SWITCH P-CHAN 1:1 8MSOP |
2,000 |
|
Datasheet |
8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad | - | Tape & Reel (TR) | Active | USB Switch | 1 | 1:1 | High Side | P-Channel | On/Off | 2.7V ~ 5.5V | Not Required | 2A | 70mOhm | Non-Inverting | Load Discharge, Status Flag | Current Limiting (Fixed), Over Temperature, Reverse Current, UVLO | -40°C ~ 85°C (TA) | - | - | Surface Mount | 8-MSOP-EP |
|
BTS61101SJAXUMA2IC PWR SWITCH N-CHAN 1:1 DSO-8 |
2,493 |
|
Datasheet |
8-SOIC (0.154", 3.90mm Width) | - | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | N-Channel | On/Off | 9V ~ 16V | Not Required | 20A | 80mOhm | - | - | Current Limiting (Fixed), Over Temperature, Over Voltage | -40°C ~ 150°C (TJ) | - | - | Surface Mount | PG-DSO-8-49 |
|
|
BV1LD080EFJ-CE2AUTOMOTIVE IPD 1CH LOW SIDE SWIT |
2,488 |
|
Datasheet |
8-SOIC (0.154", 3.90mm Width) Exposed Pad | - | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | Low Side | N-Channel | - | 40V | 3V ~ 5.5V | 3.8A | 80mOhm | Non-Inverting | Status Flag | Current Limiting (Fixed), Over Temperature, UVLO | -40°C ~ 150°C (TJ) | Automotive | AEC-Q100 | Surface Mount | 8-HTSOP-J |
|
|
MPQ5073GG-AEC1-ZIC PWR SWITCH P-CHAN 1:1 12QFN |
4,936 |
|
Datasheet |
12-VFQFN Exposed Pad | - | Tape & Reel (TR) | Active | General Purpose | 1 | 1:1 | High Side | P-Channel | - | 0.5V ~ 5.5V | 0.5V ~ 5.5V | 2A | 50mOhm | CMOS | Slew Rate Controlled | Over Temperature, Short Circuit | -40°C ~ 125°C (TJ) | - | - | Surface Mount | 12-QFN (2x2) |
|
|
ZXMS6005DN8Q-13IC PWR DRIVER N-CHAN 1:1 8SOIC |
4,894 |
|
Datasheet |
8-SOIC (0.154", 3.90mm Width) | INTELLIFET® | Tape & Reel (TR) | Active | General Purpose | 2 | 1:1 | Low Side | N-Channel | On/Off | 60V (Max) | 3.3V, 5V | 1.8A | 150mOhm | Non-Inverting | Auto Restart | Current Limiting (Fixed), Over Temperature, Over Voltage | -40°C ~ 125°C (TA) | Automotive | AEC-Q101 | Surface Mount | 8-SOIC |
Power Distribution Switches, Load Drivers Electronic Components
Explore Power Distribution Switches, Load Drivers electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
