Transistor, Photovoltaic Output Optoisolators
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Number of Channels | Voltage - Isolation | Current Transfer Ratio (Min) | Current Transfer Ratio (Max) | Turn On / Turn Off Time (Typ) | Rise / Fall Time (Typ) | Input Type | Output Type | Voltage - Output (Max) | Current - Output / Channel | Voltage - Forward (Vf) (Typ) | Current - DC Forward (If) (Max) | Vce Saturation (Max) | Grade | Qualification | Operating Temperature | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
PS2561BL-1-Q-AOPTOISOLATOR 5KV TRANS 4SMD |
0 |
|
Datasheet |
NEPOC | 4-SMD, Gull Wing | Tube | Discontinued at Digi-Key | 1 | 5000Vrms | 100% @ 5mA | 200% @ 5mA | - | 3µs, 5µs | DC | Transistor | 80V | 50mA | 1.17V | 40 mA | 300mV | - | - | -55°C ~ 110°C | Surface Mount | 4-SMD |
|
|
PS2561BL-1-W-AOPTOISOLATOR 5KV TRANS 4SMD |
0 |
|
Datasheet |
NEPOC | 4-SMD, Gull Wing | Tube | Discontinued at Digi-Key | 1 | 5000Vrms | 130% @ 5mA | 260% @ 5mA | - | 3µs, 5µs | DC | Transistor | 80V | 50mA | 1.17V | 40 mA | 300mV | - | - | -55°C ~ 110°C | Surface Mount | 4-SMD |
|
PS2561BL2-1-AOPTOISOLATOR 5KV TRANS 4SMD |
0 |
|
Datasheet |
NEPOC | 4-SMD, Gull Wing | Tube | Discontinued at Digi-Key | 1 | 5000Vrms | 100% @ 5mA | 400% @ 5mA | - | 3µs, 5µs | DC | Transistor | 80V | 50mA | 1.17V | 40 mA | 300mV | - | - | -55°C ~ 110°C | Surface Mount | 4-SMD |
|
EL205(TA)OPTOISO 3.75KV TRANS W/BASE 8SOP |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 3750Vrms | 40% @ 10mA | 80% @ 10mA | 3µs, 3µs | 1.6µs, 2.2µs | DC | Transistor with Base | 80V | - | 1.3V | 60 mA | 400mV | - | - | -55°C ~ 110°C | Surface Mount | 8-SOP |
|
|
EL206(TA)OPTOISO 3.75KV TRANS W/BASE 8SOP |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 3750Vrms | 63% @ 10mA | 125% @ 10mA | 3µs, 3µs | 1.6µs, 2.2µs | DC | Transistor with Base | 80V | - | 1.3V | 60 mA | 400mV | - | - | -55°C ~ 110°C | Surface Mount | 8-SOP |
|
|
EL207(TA)-VOPTOISO 3.75KV TRANS W/BASE 8SOP |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 3750Vrms | 100% @ 10mA | 200% @ 10mA | 3µs, 3µs | 1.6µs, 2.2µs | DC | Transistor with Base | 80V | - | 1.3V | 60 mA | 400mV | - | - | -55°C ~ 110°C | Surface Mount | 8-SOP |
|
|
EL213(TA)OPTOISO 3.75KV TRANS W/BASE 8SOP |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 3750Vrms | 100% @ 10mA | - | 3µs, 3µs | 1.6µs, 2.2µs | DC | Transistor with Base | 80V | - | 1.3V | 60 mA | 400mV | - | - | -55°C ~ 110°C | Surface Mount | 8-SOP |
|
|
EL213(TA)-VOPTOISO 3.75KV TRANS W/BASE 8SOP |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 3750Vrms | 100% @ 10mA | - | 3µs, 3µs | 1.6µs, 2.2µs | DC | Transistor with Base | 80V | - | 1.3V | 60 mA | 400mV | - | - | -55°C ~ 110°C | Surface Mount | 8-SOP |
|
OPIA4N33ATUOPTOISO 5KV DARL W/BASE 6SMD |
0 |
|
Datasheet |
- | 6-SMD, Gull Wing | Tube | Obsolete | 1 | 5000Vrms | 500% @ 10mA | - | - | 5µs, 60µs | DC | Darlington with Base | 30V | 150mA | 1.2V | 50 mA | 1V | - | - | -30°C ~ 100°C | Surface Mount | 6-SMD |
|
PC851XNNIP1HOPTOISOLATOR 5KV TRANS SMD |
0 |
|
Datasheet |
- | 4-SMD, Gull Wing | Tape & Reel (TR) | Active | 1 | - | - | - | - | 4µs, 5µs | DC | Transistor | 350V | 50mA | 1.2V | 50 mA | 300mV | - | - | -25°C ~ 100°C | Surface Mount | 4-SMD |
.JPG)
|
CNY17-2S(TA)-VOPTOISO 5KV TRANS W/BASE 6SMD |
0 |
|
Datasheet |
- | 6-SMD, Gull Wing | Tape & Reel (TR) | Active | 1 | 5000Vrms | 63% @ 10mA | 125% @ 10mA | 10µs, 9µs | 6µs, 8µs | DC | Transistor with Base | 80V | - | 1.65V (Max) | 60 mA | 300mV | - | - | -55°C ~ 110°C | Surface Mount | 6-SMD |
|
IL215ATOPTOISO 4KV TRANS W/BASE 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 4000Vrms | 20% @ 1mA | - | 3µs, 3µs | - | DC | Transistor with Base | 30V | - | 1V | 60 mA | 400mV | - | - | -55°C ~ 100°C | Surface Mount | 8-SOIC |
|
|
IL1206ATOPTOISO 4KV TRANS W/BASE 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 4000Vrms | 63% @ 10mA | 125% @ 10mA | 3µs, 3µs | - | DC | Transistor with Base | 70V | 50mA | 1.3V | 60 mA | 400mV | - | - | -55°C ~ 100°C | Surface Mount | 8-SOIC |
|
|
IL1208ATOPTOISO 4KV TRANS W/BASE 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | 1 | 4000Vrms | 100% @ 10mA | 320% @ 10mA | 3µs, 3µs | - | DC | Transistor with Base | 70V | 50mA | 1.3V | 60 mA | 400mV | - | - | -55°C ~ 100°C | Surface Mount | 8-SOIC |
|
|
TCET2200GOPTOISOLATR 5.3KV 2CH TRANS 8DIP |
0 |
|
- |
- | 8-DIP (0.400", 10.16mm) | Tube | Active | 2 | 5300Vrms | 50% @ 5mA | 600% @ 5mA | 6µs, 5µs | 3µs, 4.7µs | DC | Transistor | 70V | 50mA | 1.25V | 60 mA | 300mV | - | - | -55°C ~ 100°C | Through Hole | 8-DIP |
|
MOCD208R2VMOPTOISO 2.5KV 2CH TRANS 8SOIC |
0 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Obsolete | 2 | 2500Vrms | 40% @ 10mA | 125% @ 10mA | 7.5µs, 5.7µs | 3.2µs, 4.7µs | DC | Transistor | 70V | 150mA | 1.25V | 60 mA | 400mV | - | - | -40°C ~ 100°C | Surface Mount | 8-SOIC |
|
PC702V0YSZXOPTOISO 5KV TRANS W/BASE 6DIP |
0 |
|
Datasheet |
- | 6-DIP (0.300", 7.62mm), 5 Leads | Tube | Obsolete | 1 | 5000Vrms | - | - | - | 2µs, 2µs | DC | Transistor with Base | 70V | 50mA | 1.4V | 60 mA | 400mV | - | - | -55°C ~ 100°C | Through Hole | 6-DIP |
|
|
PC715V0YSZXOPTOISOLTR 5KV DARLINGTON 6-DIP |
0 |
|
Datasheet |
- | 6-DIP (0.300", 7.62mm), 5 Leads | Tube | Obsolete | 1 | 5000Vrms | 600% @ 1mA | 7500% @ 1mA | - | 60µs, 53µs | DC | Darlington | 35V | 80mA | 1.2V | 50 mA | 1V | - | - | -25°C ~ 100°C | Through Hole | 6-DIP |
|
|
PC723V0NSZXOPTOISO 5KV TRANS W/BASE 6DIP |
0 |
|
Datasheet |
- | 6-DIP (0.300", 7.62mm) | Tube | Obsolete | 1 | 5000Vrms | - | - | - | 6µs, 7µs | DC | Transistor with Base | 80V | 50mA | 1.2V | 50 mA | 300mV | - | - | -25°C ~ 100°C | Through Hole | 6-DIP |
|
H11G16PIN DARLINGTON OUTPUT, HIGH VOL |
0 |
|
- |
H11G | 6-DIP (0.400", 10.16mm) | Tube | Active | 1 | 5300Vrms | - | - | - | 100µs, 20µs | DC | Darlington with Base | 100V | 150mA | 1.2V | 50 mA | 1.2V | - | - | -25°C ~ 100°C | Through Hole | 6-DIP |
