Limit Switches
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Circuit | Switch Function | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Actuator Type | Mounting Type | Termination Style | Ingress Protection | Features | Operating Force | Release Force | Operating Position | Pretravel | Differential Travel | Overtravel | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
608.8871.020SWITCH LIMIT PLASTIC BODY |
0 |
|
- |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
D4E-1H20NSWITCH SNAP ACTION SPDT 5A 125V |
0 |
|
Datasheet |
D4E-xN | Bulk | Active | SPDT | On-Mom | 5A (AC/DC) | 125 V | 30 V | Lever, Roller | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | 400gf | 80gf | 1.350" (34.3mm) | 0.080" (2.0mm) | 0.012" (0.3mm) | 0.158" (4.0mm) | -10°C ~ 80°C |
|
|
D4MC-2022 VCT 3MSWITCH SNAP ACTION SPDT 10A 125V |
0 |
|
Datasheet |
D4MC | Bulk | Active | SPDT | On-Mom | 10A (AC), 6A (DC) | 125 V | 30 V | Lever, Roller | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | Cable Length 3m | 300gf | 40gf | 1.575" (40.0mm) | - | 0.060" (1.5mm) | 0.079" (2.0mm) | -10°C ~ 80°C |
|
|
SHL-W155-ML VCTF 3MSWITCH SNAP ACTION SPDT 10A 125V |
0 |
|
Datasheet |
SHL | Bulk | Active | SPDT | On-Mom | 10A (AC), 5A (DC) | 125 V | 30 V | Lever, Straight | Chassis Mount | Cable Leads | IP67 - Dust Tight, Waterproof | - | 240gf | 45gf | 0.846" (21.5mm) | 0.512" (13.0mm) | 0.156" (4.0mm) | 0.197" (5.0mm) | -10°C ~ 80°C |
|
|
ZE-YN-2SWITCH SNAP ACTION SPDT 15A 125V |
0 |
|
Datasheet |
ZE | Bulk | Active | SPDT | On-Mom | 15A (AC), 500mA (DC) | 125 V | 125 V | - | Chassis Mount | Screw Terminal | - | - | - | - | - | - | - | - | -10°C ~ 80°C |
|
|
ZV2-Q-2SSWITCH SNAP ACTION SPDT 15A 125V |
0 |
|
Datasheet |
ZV2 | Bulk | Active | SPDT | On-Mom | 15A (AC), 500mA (DC) | 125 V | 125 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP60 - Dust Tight | - | 250 ~ 350gf | 114gf | 0.953" (24.2mm) | 0.015" (0.4mm) | 0.002" (0.05mm) | 0.217" (5.5mm) | -10°C ~ 80°C |
|
GLBC02BSWITCH SNAP ACTION SPDT 6A 120V |
0 |
|
Datasheet |
GLS | Bulk | Obsolete | SPDT | On-Mom | 6A (AC), 550mA (DC) | 120 V | 125 V | Round (Pin Plunger) | Chassis Mount | Plug In | IP67 - Dust Tight, Waterproof | - | 1632gf | - | 1.380" (35.0mm) | 0.100" (2.5mm) | 0.035" (0.9mm) | 0.180" (4.6mm) | -25°C ~ 85°C |
|
|
GLAA01B-F058SWITCH SNAP ACTION LIMIT |
0 |
|
- |
GLA | Bulk | Obsolete | - | - | - | - | - | Side Rotary, Roller | Chassis Mount | Screw Terminal | IP67 - Dust Tight, Waterproof | - | - | - | - | - | - | - | -25°C ~ 85°C |
|
XCKP2145P16SWITCH LIMIT DPST 3A 240V |
0 |
|
Datasheet |
XCKP | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Side Rotary, Adjustable Roller | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
XCKP2511G11SWITCH LIMIT DPST 3A 240V |
0 |
|
Datasheet |
XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
XCKP2511P16SWITCH LIMIT DPST 3A 240V |
0 |
|
Datasheet |
XC | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 3A (AC), 270mA (DC) | 240 V | 250 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -25°C ~ 70°C |
|
|
51.603BFOOT SWITCHFM1SU1F2BK SPDTMOM2MC |
0 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
|
51.603GFOOT SWITCHFM1SU1F2GY SPDTMOM2MC |
0 |
|
Datasheet |
* | Bulk | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
3SE51320CB01SWITCH LIMIT DPST 6A 125V |
0 |
|
Datasheet |
3SE5 | Box | Active | DPST-NO/NC | On-Mom, Off-Mom | 6A (AC), 3A (DC) | 125 V | 24 V | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | 2039gf | - | - | - | - | - | -25°C ~ 85°C |
|
|
608.7000.096SWITCH LIMIT 4PST 1.5A 240V |
0 |
|
Datasheet |
MN78 | Bulk | Active | 4PST-3NO/1NC | On-Off, Off-On | 1.5A (AC/DC) | 240 V | 24 V | Side Rotary, Adjustable Rod | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -30°C ~ 75°C |
|
|
608.7000.095SWITCH LIMIT 4PST 1.5A 240V |
0 |
|
Datasheet |
MN78 | Bulk | Active | 4PST-3NC/1NO | On-Off, Off-On | 1.5A (AC/DC) | 240 V | 24 V | Side Rotary, Adjustable Rod | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -30°C ~ 75°C |
|
|
608.7000.094SWITCH LIMIT 4PST-NO 1.5A 240V |
0 |
|
Datasheet |
MN78 | Bulk | Active | 4PST-NO | Off-On | 1.5A (AC/DC) | 240 V | 24 V | Side Rotary, Adjustable Rod | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -30°C ~ 75°C |
|
|
608.7000.093SWITCH LIMIT 4PST-NC 1.5A 240V |
0 |
|
Datasheet |
MN78 | Bulk | Active | 4PST-NC | On-Off | 1.5A (AC/DC) | 240 V | 24 V | Side Rotary, Adjustable Rod | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -30°C ~ 75°C |
|
|
608.7000.092SWITCH LIMIT 4PST 1.5A 240V |
0 |
|
Datasheet |
MN78 | Bulk | Active | 4PST-2NO/2NC | On-Off, Off-On | 1.5A (AC/DC) | 240 V | 24 V | Side Rotary, Adjustable Rod | Chassis Mount | Screw Terminal | IP66/IP67 - Dust Tight, Water Resistant, Waterproof | - | - | - | - | - | - | - | -30°C ~ 75°C |
|
SI-LM40PBDSWITCH SAFETY LIMIT DPST 6A 120V |
0 |
|
Datasheet |
SI-LM40 | Bulk | Obsolete | DPST-NO/NC | On-Mom, Off-Mom | 6A (AC) | 120 V | - | Round (Pin Plunger) | Chassis Mount | Screw Terminal | IP65 - Dust Tight, Water Resistant | - | - | - | - | - | - | - | -30°C ~ 80°C |
Limit Switches Electronic Components
Frequently Asked Questions
Q1: What products are included in Limit Switches?
This category includes related Limit Switches subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Limit Switches components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Limit Switches and other electronic components.
