Fuses
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Mounting Type | Fuse Type | Current Rating (Amps) | Voltage Rating - AC | Voltage Rating - DC | Response Time | Breaking Capacity @ Rated Voltage | Melting I²t | Approval Agency | Operating Temperature | Color | Size / Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
7022.0750FUSE CERM 100MA 660VAC 3AB 3AG |
7,189 |
|
Datasheet |
A12FA | Bulk | Active | Requires Holder | Cartridge, Ceramic | 100 mA | 660 V | - | Fast Blow | 30kA | 0.0017 | UR | -40°C ~ 85°C | - | 0.250" Dia x 1.252" L (6.35mm x 31.80mm) | |
|
0487010.MXPFUSE CERAMIC 10A 420VAC 420VDC |
4,992 |
|
Datasheet |
487 | Bulk | Active | Requires Holder | Cartridge, Ceramic | 10 A | 420 V | 420 V | Fast Blow | 200A AC, 300A DC | 130.0 | TUV, UR | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
0456040.DRFUSE BOARD MOUNT 40A 60VDC 2SMD |
9,395 |
|
Datasheet |
NANO²® 456 | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 40 A | - | 60 V | Fast Blow | 600A | 454.0 | cULus | -55°C ~ 125°C | - | 0.492" L x 0.175" W x 0.175" H (12.50mm x 4.45mm x 4.45mm) | |
|
0504030.MXEPFUSE CERM 30A 500VAC 420VDC 3AB |
6,000 |
|
Datasheet |
504 | Bulk | Active | Through Hole | Cartridge, Ceramic | 30 A | 500 V | 420 V | - | 200A AC, 400A DC | 2600.0 | CE, cURus | -55°C ~ 125°C | - | 0.275" Dia x 1.288" L (6.99mm x 32.72mm) | |
|
0ADBP3000-REFUSE CERM 3A 1KVAC 1KVDC 3AB 3AG |
7,814 |
|
Datasheet |
0ADBP | Bulk | Active | Through Hole | Cartridge, Ceramic | 3 A | 1 kV | 1 kV | Fast Blow | 10kA | 7.54 | cURus | -55°C ~ 125°C | - | 0.266" Dia x 1.292" H (6.76mm x 32.82mm) | |
|
0273003.HFUSE BRD MNT 3A 125VAC/VDC RAD |
3,071 |
|
Datasheet |
MICRO™ 273 | Bulk | Active | Through Hole | Board Mount (Cartridge Style Excluded) | 3 A | 125 V | 125 V | Fast Blow | 10kA | 0.759 | CSA, QPL, UL | -55°C ~ 85°C | - | 0.250" Dia x 0.350" H (6.35mm x 8.89mm) | |
|
0881070.URFUSE BOARD MOUNT 70A 75VDC 2SMD |
5,911 |
|
Datasheet |
881 | Tape & Reel (TR) | Active | Surface Mount | Board Mount (Cartridge Style Excluded) | 70 A | - | 75 V | - | 1.5kA | 1250.0 | cURus | -55°C ~ 100°C | - | 0.394" L x 0.441" W x 0.268" H (10.00mm x 11.20mm x 6.80mm) | |
|
0998400.UX-2M8FUSE AUTO 400A 70VDC AUTO LINK |
2,346 |
|
Datasheet |
MEGA® | Bulk | Active | Bolt Mount | Automotive | 400 A | - | 70 V | - | 2.5kA | - | - | -40°C ~ 125°C | Purple | 1.150" L x 0.750" W x 0.390" H (29.20mm x 19.05mm x 9.90mm) | |
|
0607050.UXTH500PFUSE CERM 50A 500VAC 500VDC RAD |
7,994 |
|
Datasheet |
607 | Tray | Active | Through Hole | Cartridge, Ceramic | 50 A | 500 V | 500 V | - | 10kA | 4230.0 | cURus, TUV | -55°C ~ 125°C | - | 0.482" Dia x 1.315" L (12.25mm x 33.40mm) | |
|
0828020.ZXISOPFUSE CERAMIC 20A 1KVDC BOLT DOWN |
6,935 |
|
Datasheet |
828 | Tray | Active | Bolt Mount | Cartridge, Ceramic | 20 A | - | 1 kV | - | 10kA | 536.0 | cURus | -55°C ~ 125°C | - | 0.482" Dia x 1.543" L (12.25mm x 39.20mm) | |
|
166.7000.5252FUSE AUTO 25A 80VDC BLADE ATO |
8,691 |
|
Datasheet |
FKS ATO® | Bulk | Active | Requires Holder | Automotive | 25 A | - | 80 V | Slow Blow | 1kA | 950.0 | cULus | - | Clear | 0.748" L x 0.197" W x 0.520" H (19.00mm x 5.00mm x 13.20mm) | |
|
FMC16202WBTPFUSE CHIP 2A 32VDC 0603 |
66 |
|
Datasheet |
- | Tape & Reel (TR) | Active | Surface Mount | - | 2 A | - | 32 V | - | 35A | - | CSA, UL | -55°C ~ 125°C | - | 0.063" L x 0.031" W x 0.018" H (1.60mm x 0.80mm x 0.45mm) | |
|
|
FCC16151ADTPFUSE CHIP 0.15A 36VDC 0603 |
4,654 |
|
Datasheet |
- | Tape & Reel (TR) | Active | Surface Mount | - | 150 mA | - | 50 V | - | 35A | - | CSA, UL | -55°C ~ 125°C | - | 0.063" L x 0.031" W x 0.018" H (1.60mm x 0.80mm x 0.45mm) | |
|
061701.6MXPFUSE GLASS 1.6A 250VAC 5X20MM |
68 |
|
Datasheet |
617 | Bulk | Active | Requires Holder | Cartridge, Glass | 1.6 A | 250 V | - | Fast Blow | 35A | 4.615 | CCC, CE, CSA, UR. VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
0617.500MXPFUSE GLASS 500MA 250VAC 5X20MM |
3,195 |
|
Datasheet |
617 | Bulk | Active | Requires Holder | Cartridge, Glass | 500 mA | 250 V | - | Fast Blow | 35A | 0.215 | CCC, CE, CSA, UR. VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
0617002.MXPFUSE GLASS 2A 250VAC 5X20MM |
8,015 |
|
Datasheet |
617 | Bulk | Active | Requires Holder | Cartridge, Glass | 2 A | 250 V | - | Fast Blow | 35A | 5.73 | CCC, CE, CSA, UR. VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
061706.3MXPFUSE GLASS 6.3A 250VAC 5X20MM |
4,489 |
|
Datasheet |
617 | Bulk | Active | Requires Holder | Cartridge, Glass | 6.3 A | 250 V | - | Fast Blow | 63A | 62.465 | CCC, CE, CSA, UR. VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
029707.5WXTFUSE AUTO 7.5A 32VDC BLADE MINI |
4,400 |
|
Datasheet |
MINI® 297 | Bulk | Active | Requires Holder | Automotive | 7.5 A | - | 32 V | Fast Blow | 1kA | 68.0 | UR | -40°C ~ 125°C | Brown | 0.429" L x 0.150" W x 0.346" H (10.90mm x 3.80mm x 8.80mm) | |
|
|
0618002.MXPFUSE GLASS 2A 250VAC 5X20MM |
6,534 |
|
Datasheet |
618 | Bulk | Active | Requires Holder | Cartridge, Glass | 2 A | 250 V | - | Slow Blow | 35A | 14.45 | CCC, CE, CSA, UR, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) | |
|
|
0618004.MXPFUSE GLASS 4A 250VAC 5X20MM |
9,471 |
|
Datasheet |
618 | Bulk | Active | Requires Holder | Cartridge, Glass | 4 A | 250 V | - | Slow Blow | 40A | 69.1 | CCC, CE, CSA, UR, VDE | -55°C ~ 125°C | - | 0.205" Dia x 0.787" L (5.20mm x 20.00mm) |
Fuses Electronic Components
Frequently Asked Questions
Q1: What products are included in Fuses?
This category includes related Fuses subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Fuses components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Fuses and other electronic components.
