Film Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Capacitance | Tolerance | Voltage Rating - AC | Voltage Rating - DC | Dielectric Material | ESR (Equivalent Series Resistance) | Operating Temperature | Mounting Type | Size / Dimension | Height - Seated (Max) | Termination | Lead Spacing | Applications | Ratings | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
100MU222KA13216CAP FILM 2200PF 10% 100VDC 1206 |
7,297 |
|
Datasheet |
1206 (3216 Metric) | 2200 pF | ±10% | - | 100V | Acrylic, Metallized | - | -55°C ~ 125°C | Surface Mount | 0.126" L x 0.063" W (3.20mm x 1.60mm) | 0.047" (1.20mm) | Solder Pads | - | DC Link, DC Filtering | - | - |
|
B33331V7405J080CAP FILM 4UF 5% 460VAC RADIAL |
4,815 |
|
Datasheet |
Radial, Can | 4 µF | ±5% | 460V | - | Polypropylene (PP), Metallized | 23 mOhms | -40°C ~ 85°C | Chassis Mount | 1.181" Dia (30.00mm) | 2.638" (67.00mm) | Quick Connect - 0.250" (6.3mm) | - | General Purpose | - | - |
|
B32686A1104K000CAP FILM 0.1UF 10% 1.6KVDC RAD |
8,186 |
|
Datasheet |
Radial | 0.1 µF | ±10% | 450V | 1600V (1.6kV) | Polypropylene (PP), Metallized | - | -55°C ~ 100°C | Through Hole | 1.654" L x 0.709" W (42.00mm x 18.00mm) | 1.280" (32.50mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering; High Pulse, DV/DT; Snubber | - | - |
|
MMWA2P22K-FCAP FILM 0.22UF 10% 250VDC AXIAL |
1 |
|
Datasheet |
Axial | 0.22 µF | ±10% | 125V | 250V | Polyester, Metallized | - | -55°C ~ 125°C | Through Hole | 0.311" Dia x 0.685" L (7.90mm x 17.40mm) | - | PC Pins | - | General Purpose | - | - |
|
MKP1848C53090JK2CAP FILM 3UF 5% 900VDC RADIAL |
8,485 |
|
Datasheet |
Radial | 3 µF | ±5% | - | 900V | Polypropylene (PP), Metallized | 20 mOhms | -55°C ~ 105°C | Through Hole | 1.260" L x 0.512" W (32.00mm x 13.00mm) | 0.906" (23.00mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering | - | Low ESR; Low ESL; Long Life |
|
BLH126K451A072DC LINK, THB, 85/85, AEC-Q200 |
7,869 |
|
Datasheet |
Radial | 12 µF | ±10% | - | 450V | Polypropylene (PP), Metallized | 7 mOhms | -40°C ~ 105°C | Through Hole | 1.260" L x 0.709" W (32.00mm x 18.00mm) | 1.331" (33.80mm) | PC Pins | 1.083" (27.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | 85C/85% Humidity, THB, Low ESR, Low ESL, Long Life |
|
C4AEJBU4800A11JCAP FILM 8UF 5% 700VDC RADIAL |
13 |
|
Datasheet |
Radial | 8 µF | ±5% | - | 700V | Polypropylene (PP), Metallized | 7.3 mOhms | -40°C ~ 85°C | Through Hole | 1.240" L x 0.748" W (31.50mm x 19.00mm) | 1.150" (29.20mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering; High Frequency, Switching | - | - |
|
SMDIJ02100XA00MT00CAP FILM 10000PF 20% 630VDC 5040 |
3,889 |
|
Datasheet |
5040 (127102 Metric) | 10000 pF | ±20% | 300V | 630V | Polyphenylene Sulfide (PPS), Metallized | - | -55°C ~ 140°C | Surface Mount | 0.500" L x 0.402" W (12.70mm x 10.20mm) | 0.248" (6.30mm) | Solder Pads | - | General Purpose | - | - |
|
PSB2253100KHSCAP FILM 0.1UF 10% 2.5KVDC RAD |
9,840 |
|
Datasheet |
Radial | 0.1 µF | ±10% | 725V | 2500V (2.5kV) | Polypropylene (PP), Metallized | 7.6 mOhms | -40°C ~ 85°C | Through Hole | 1.043" L x 0.512" W (26.50mm x 13.00mm) | 0.866" (22.00mm) | PC Pins | 0.886" (22.50mm) | High Frequency, Switching; High Pulse, DV/DT; Snubber | - | - |
|
B32676T4405K000CAP FILM 4UF 10% 450VDC RADIAL |
3,531 |
|
Datasheet |
Radial | 4 µF | ±10% | - | 450V | Polypropylene (PP), Metallized | 15.5 mOhms | -40°C ~ 105°C | Through Hole | 1.634" L x 0.945" W (41.50mm x 24.00mm) | 0.591" (15.00mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering | - | Long Life |
|
B32654A3335J000CAP FILM 3.3UF 5% 250VDC RADIAL |
10 |
|
Datasheet |
Radial | 3.3 µF | ±5% | 160V | 250V | Polypropylene (PP), Metallized | - | -55°C ~ 100°C | Through Hole | 1.240" L x 0.591" W (31.50mm x 15.00mm) | 0.965" (24.50mm) | PC Pins | 1.083" (27.50mm) | DC Link, DC Filtering; High Pulse, DV/DT | AEC-Q200 | - |
|
WMF2P22K-FCAP FILM 0.22UF 10% 250VDC AXIAL |
13 |
|
Datasheet |
Axial | 0.22 µF | ±10% | - | 250V | Polyester | - | -55°C ~ 125°C | Through Hole | 0.413" Dia x 1.185" L (10.50mm x 30.10mm) | - | PC Pins | - | General Purpose | - | - |
|
QXP2G105KRPTCAP FILM 1UF 10% 400VDC RADIAL |
2 |
|
Datasheet |
Radial | 1 µF | ±10% | 160V | 400V | Polypropylene (PP), Metallized | - | -40°C ~ 105°C | Through Hole | 1.240" L x 0.512" W (31.50mm x 13.00mm) | 0.898" (22.80mm) | PC Pins | 1.083" (27.50mm) | High Frequency, Switching | - | - |
|
B32526T6825K000CAP FILM 8.2UF 10% 400VDC RADIAL |
2,135 |
|
Datasheet |
Radial | 8.2 µF | ±10% | 200V | 400V | Polyester, Polyethylene Terephthalate (PET) | - | -55°C ~ 125°C | Through Hole | 1.634" L x 0.945" W (41.50mm x 24.00mm) | 0.748" (19.00mm) | PC Pins | 1.476" (37.50mm) | Automotive; EMI, RFI Suppression | - | - |
|
890324027025CSCAP FILM 3.3UF 10% 275VAC RADIAL |
6,085 |
|
Datasheet |
Radial | 3.3 µF | ±10% | 275V | - | Polypropylene (PP), Metallized | - | -40°C ~ 105°C | Through Hole | 1.220" L x 0.610" W (31.00mm x 15.50mm) | 1.161" (29.50mm) | PC Pins | 1.083" (27.50mm) | EMI, RFI Suppression | X2 | - |
|
R76PR34704030JCAP FILM 0.47UF 5% 630VDC RADIAL |
6,021 |
|
Datasheet |
Radial | 0.47 µF | ±5% | 400V | 630V | Polypropylene (PP), Metallized | - | -55°C ~ 110°C | Through Hole | 1.260" L x 0.512" W (32.00mm x 13.00mm) | 0.870" (22.10mm) | PC Pins | 1.083" (27.50mm) | High Frequency, Switching; High Pulse, DV/DT | - | - |
|
|
B32686A2683J000CAP FILM 0.068UF 5% 2KVDC RADIAL |
9,847 |
|
Datasheet |
Radial | 0.068 µF | ±5% | 500V | 2000V (2kV) | Polypropylene (PP), Metallized | - | -55°C ~ 100°C | Through Hole | 1.654" L x 0.709" W (42.00mm x 18.00mm) | 1.122" (28.50mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering; High Pulse, DV/DT; Snubber | - | - |
|
B32656T7274K000CAP FILM 0.27UF 10% 1.25KVDC RAD |
5,176 |
|
Datasheet |
Radial | 0.27 µF | ±10% | 500V | 1250V (1.25kV) | Polypropylene (PP), Metallized | - | -55°C ~ 100°C | Through Hole | 1.634" L x 0.945" W (41.50mm x 24.00mm) | 0.591" (15.00mm) | PC Pins | 1.476" (37.50mm) | DC Link, DC Filtering; High Pulse, DV/DT | - | - |
|
R41BR347050T0KCAP FILM 0.47UF 10% 1.5KVDC RAD |
3 |
|
Datasheet |
Radial | 0.47 µF | ±10% | 350V | 1500V (1.5kV) | Polypropylene (PP), Metallized | - | -40°C ~ 125°C | Through Hole | 1.260" L x 0.709" W (32.00mm x 18.00mm) | 1.303" (33.10mm) | PC Pins | 1.083" (27.50mm) | Automotive; EMI, RFI Suppression | AEC-Q200, X1, Y2 | - |
|
|
BLH106K801A082DC LINK, THB, 85/85, AEC-Q200 |
2,338 |
|
Datasheet |
Radial | 10 µF | ±10% | - | 800V | Polypropylene (PP), Metallized | 9.5 mOhms | -40°C ~ 105°C | Through Hole | 1.260" L x 0.709" W (32.00mm x 18.00mm) | 1.488" (37.80mm) | PC Pins | 1.083" (27.50mm) | Automotive; DC Link, DC Filtering | AEC-Q200 | 85C/85% Humidity, THB, Low ESR, Low ESL, Long Life |
Film Capacitors Electronic Components
Frequently Asked Questions
Q1: What products are included in Film Capacitors?
This category includes related Film Capacitors subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Film Capacitors components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Film Capacitors and other electronic components.
