FET, MOSFET Arrays
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Technology | Configuration | FET Feature | Drain to Source Voltage (Vdss) | Current - Continuous Drain (Id) @ 25°C | Rds On (Max) @ Id, Vgs | Vgs(th) (Max) @ Id | Gate Charge (Qg) (Max) @ Vgs | Input Capacitance (Ciss) (Max) @ Vds | Power - Max | Operating Temperature | Grade | Qualification | Mounting Type | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
SSM6P41FE(TE85L,F)MOSFET 2P-CH 20V 0.72A ES6 |
10,848 |
|
Datasheet |
- | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 20V | 720mA | 300mOhm @ 400mA, 4.5V | 1V @ 1mA | 1.76nC @ 4.5V | 110pF @ 10V | 150mW | 150°C (TJ) | - | - | Surface Mount | ES6 |
|
MCQ4953-TPMOSFET 2P-CH 30V 5A 8SOP |
3,894 |
|
Datasheet |
- | 8-SOIC (0.154", 3.90mm Width) | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | - | 30V | 5A | 60mOhm @ 4.9A, 10V | 2.5V @ 250µA | 25nC @ 10V | - | 2.5W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | 8-SOP |
|
SI1023CX-T1-GE3MOSFET 2P-CH 20V SC89 |
50,405 |
|
Datasheet |
TrenchFET® | SOT-563, SOT-666 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 20V | - | 756mOhm @ 350mA, 4.5V | 1V @ 250µA | 2.5nC @ 4.5V | 45pF @ 10V | 220mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-89 (SOT-563F) |
|
DMC2038LVTQ-7MOSFET N/P-CH 20V 3.7A TSOT23-6 |
15,410 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Not For New Designs | MOSFET (Metal Oxide) | N and P-Channel Complementary | Logic Level Gate, 1.8V Drive | 20V | 3.7A (Ta), 2.6A (Ta) | 35mOhm @ 4A, 4.5V, 74mOhm @ 3A, 4.5V | 1V @ 250µA | 5.7nC @ 4.5V, 10nC @ 4.5V | 530pF @ 10V, 705pF @ 10V | 800mW (Ta) | -55°C ~ 150°C (TJ) | Automotive | AEC-Q101 | Surface Mount | TSOT-23-6 |
|
SSM6P40TU,LFMOSFET 2P-CH 30V 1.4A UF6 |
14,001 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate, 4V Drive | 30V | 1.4A (Ta) | 226mOhm @ 1A, 10V | 2V @ 1mA | 2.9nC @ 10V | 120pF @ 15V | 500mW (Ta) | 150°C | - | - | Surface Mount | UF6 |
|
SI1902CDL-T1-BE3MOSFET 2N-CH 20V 1A SC70-6 |
5,985 |
|
Datasheet |
TrenchFET® | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 20V | 1A (Ta), 1.1A (Tc) | 235mOhm @ 1A, 4.5V | 1.5V @ 250µA | 3nC @ 10V | 62pF @ 10V | 300mW (Ta), 420mW (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-70-6 |
|
DMN2041UVT-7MOSFET 2N-CH 20V 5.8A TSOT26 |
1,946 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 20V | 5.8A (Ta) | 28mOhm @ 8.2A, 4.5V | 900mV @ 250µA | 9.1nC @ 4.5V | 689pF @ 10V | 1.1W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TSOT-26 |
|
|
DMC3060LVT-7MOSFET N/P-CH 30V 3.6A TSOT23-6 |
14,086 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel Complementary | - | 30V | 3.6A (Ta), 2.8A (Ta) | 60mOhm @ 3.1A, 10V, 95mOhm @ 2.7A, 10V | 1.8V @ 250µA, 2.1V @ 250µA | 11.3nC @ 10V | 395pF @ 15V, 324pF @ 15V | 830mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TSOT-23-6 |
|
SIL3724A-TPMOSFET N/P-CH 30V 4.5A SOT23-6L |
4,070 |
|
Datasheet |
- | SOT-23-6 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | - | 30V | 4.5A, 3.5A | 35mOhm @ 3A, 10V, 90mOhm @ 3A, 10V | 2.5V @ 250µA | 6.08nC @ 15V | 315pF @ 10V, 365pF @ 10V | 2W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-23-6L |
|
DMP2075UFDB-7MOSFET 2P-CH 20V 3.8A 6UDFN |
69,950 |
|
Datasheet |
- | 6-UDFN Exposed Pad | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | - | 20V | 3.8A (Ta) | 75mOhm @ 2.9A, 4.5V | 1.4V @ 250µA | 8.8nC @ 4.5V | 642pF @ 10V | 700mW (Ta) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | U-DFN2020-6 (Type B) |
|
DMN2005DLP4K-7MOSFET 2N-CH 20V 0.3A 6DFN |
26,340 |
|
Datasheet |
- | 6-XFDFN Exposed Pad | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | - | 20V | 300mA | 1.5Ohm @ 10mA, 4V | 900mV @ 100µA | - | - | 400mW | -65°C ~ 150°C (TJ) | - | - | Surface Mount | X2-DFN1310-6 (Type B) |
|
|
SI1553CDL-T1-GE3MOSFET N/P-CH 20V 0.7A SC70-6 |
5,893 |
|
Datasheet |
TrenchFET® | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 20V | 700mA, 500mA | 390mOhm @ 700mA, 4.5V | 1.5V @ 250µA | 1.8nC @ 10V | 38pF @ 10V | 340mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-70-6 |
|
|
SI1553CDL-T1-BE3MOSFET N/P-CH 20V 0.7A SC70-6 |
2,400 |
|
Datasheet |
TrenchFET® | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | - | 20V | 700mA (Ta), 700mA (Tc), 400mA (Ta), 500mA (Tc) | 390mOhm @ 700mA, 4.5V, 850mOhm @ 400mA, 4.5V | 1.5V @ 250µA | 1.8nC @ 10V, 3nC @ 10V | 38pF @ 10V, 43pF @ 10V | 290mW (Ta), 340mW (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-70-6 |
|
|
SSM6L12TU,LFMOSFET N/P-CH 30V/20V 0.5A UF6 |
1,787 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | - | 30V, 20V | 500mA (Ta) | 145mOhm @ 500mA, 4.5V, 260mOhm @ 250mA, 4V | 1.1V @ 100µA | - | 245pF @ 10V, 218pF @ 10V | 500mW | 150°C | - | - | Surface Mount | UF6 |
|
|
SSM6P54TU,LFMOSFET 2P-CH 20V 1.2A UF6 |
7,515 |
|
Datasheet |
- | 6-SMD, Flat Leads | Tape & Reel (TR) | Last Time Buy | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate, 1.5V Drive | 20V | 1.2A (Ta) | 228mOhm @ 600mA, 2.5V | 1V @ 1mA | 7.7nC @ 4V | 331pF @ 10V | 500mW (Ta) | 150°C | - | - | Surface Mount | UF6 |
|
|
DMN2050LFDB-13MOSFET 2N-CH 20V 3.3A 6UDFN |
17,537 |
|
Datasheet |
- | 6-UDFN Exposed Pad | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 N-Channel (Dual) | Logic Level Gate | 20V | 3.3A | 45mOhm @ 5A, 4.5V | 1V @ 250µA | 12nC @ 10V | 389pF @ 10V | 730mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | U-DFN2020-6 (Type B) |
|
DMC31D5UDJ-7BMOSFET N/P-CH 30V 0.22A SOT963 |
26,724 |
|
Datasheet |
- | SOT-963 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | Logic Level Gate | 30V | 220mA, 200mA | 1.5Ohm @ 100mA, 4.5V | 1V @ 250µA | 0.38nC @ 4.5V | 22.6pF @ 15V | 350mW | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SOT-963 |
|
|
SI1967DH-T1-E3MOSFET 2P-CH 20V 1.3A SC70-6 |
8,875 |
|
Datasheet |
TrenchFET® | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | Logic Level Gate | 20V | 1.3A | 490mOhm @ 910mA, 4.5V | 1V @ 250µA | 4nC @ 8V | 110pF @ 10V | 1.25W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-70-6 |
|
|
DMC25D0UVT-7MOSFET N/P-CH 25V/30V TSOT23 |
7,433 |
|
Datasheet |
- | SOT-23-6 Thin, TSOT-23-6 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | N and P-Channel | - | 25V, 30V | 400mA, 3.2A | 4Ohm @ 400mA, 4.5V | 1.5V @ 250µA | 0.7nC @ 8V | 26.2pF @ 10V | 1.2W | -55°C ~ 150°C (TJ) | - | - | Surface Mount | TSOT-23-6 |
|
|
SI1967DH-T1-BE3MOSFET 2P-CH 20V 1A SC70-6 |
7,019 |
|
Datasheet |
TrenchFET® | 6-TSSOP, SC-88, SOT-363 | Tape & Reel (TR) | Active | MOSFET (Metal Oxide) | 2 P-Channel (Dual) | - | 20V | 1A (Ta), 1.3A (Tc) | 490mOhm @ 910mA, 4.5V | 1V @ 250µA | 4nC @ 10V | 110pF @ 10V | 740mW (Ta), 1.25W (Tc) | -55°C ~ 150°C (TJ) | - | - | Surface Mount | SC-70-6 |
