Electric Double Layer Capacitors (EDLC), Supercapacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Termination | Mounting Type | Package / Case | Lead Spacing | Size / Dimension | Height - Seated (Max) | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
XL60-2R9348W-RCAP 3400F 2.85V BUTTON |
1 |
|
Datasheet |
XL60 | Bulk | Active | 3400 F | 0%, +20% | 2.85 V | 0.23mOhm | 1500 Hrs @ 65°C | Weld Stud | Chassis Mount | Axial, Can | - | 2.390" Dia x 5.433" L (60.70mm x 138.00mm) | - | -40°C ~ 65°C |
|
RSDZN1052R7E22300TCAP 1F -20% +80% 2.7V T/H |
0 |
|
Datasheet |
DZN | Bulk | Not For New Designs | 1 F | -20%, +80% | 2.7 V | 300mOhm @ 1kHz | 1000 Hrs @ 70°C | PC Pins | Through Hole | Radial, Can | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.945" (24.00mm) | -25°C ~ 70°C |
|
FYH0H223ZFCAP 22MF -20% +80% 5.5V T/H |
0 |
|
Datasheet |
FYH | Bulk | Active | 22 mF | -20%, +80% | 5.5 V | 200Ohm @ 1kHz | - | PC Pins | Through Hole | Radial, Can | 0.200" (5.08mm) | 0.453" Dia (11.50mm) | 0.276" (7.00mm) | -25°C ~ 70°C |
|
M0510-2R5204-RCAP 200MF -20% +80% 2.5V T/H |
0 |
|
Datasheet |
M | Bulk | Active | 200 mF | -20%, +80% | 2.5 V | - | 1000 Hrs @ 60°C | PC Pins | Through Hole | Radial, Can | - | - | - | -40°C ~ 60°C |
|
RSCVN1045R5G08012TCAP 100MF -20% +80% 5.5V SMD |
2 |
|
Datasheet |
DVN | Tape & Reel (TR) | Not For New Designs | 100 mF | -20%, +80% | 5.5 V | 30Ohm | 1000 Hrs @ 70°C | SMD (SMT) Tabs | Surface Mount | Radial, Can - SMD | - | 0.492" Dia (12.50mm) | 0.335" (8.50mm) | -25°C ~ 70°C |
|
TPLC-3R8/25MR10X16CAP LITH HYBRID 25F 3.8V T/H |
14 |
|
Datasheet |
TPLC | Tray | Active | 25 F | ±20% | 3.8 V | 270mOhm @ 1kHz | 1000 Hrs @ 70°C | PC Pins | Through Hole | Radial, Can | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.709" (18.00mm) | -15°C ~ 70°C |
|
MAL223091007E3CAP 30F -20% +50% 3V T/H |
20 |
|
Datasheet |
ENYCAP™ 230 EDLC-HV, Automotive, AEC-Q200 | Tray | Active | 30 F | -20%, +50% | 3 V | 17mOhm @ 1kHz | 2000 Hrs @ 85°C | PC Pins | Through Hole | Radial, Can | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.063" (27.00mm) | -40°C ~ 85°C |
|
SCAP,PBLL-2.5/5.4CAP 2.5F 5.4V UCAP PACK |
0 |
|
Datasheet |
PBLL | Bulk | Active | 2.5 F | - | 5.4 V | 245mOhm @ 1kHz | 1000 Hrs @ 65°C | Wire Leads with Connector | User Defined | Radial, Can | - | 0.866" L x 0.472" W (22.00mm x 12.00mm) | 0.984" (25.00mm) | -40°C ~ 85°C |
|
|
SCAP,PBLL-0.47/5.4CAP 0.47F 5.4V UCAP PACK |
0 |
|
Datasheet |
PBLL | Bulk | Active | 470 mF | - | 5.4 V | 690mOhm @ 1kHz | 1000 Hrs @ 65°C | Wire Leads with Connector | User Defined | Radial, Can | - | 0.709" L x 0.394" W (18.00mm x 10.00mm) | 0.669" (17.00mm) | -40°C ~ 85°C |
|
MAL222091003E3CAP 20F -20% +50% 2.7V T/H |
0 |
|
Datasheet |
ENYCAP™ 220 EDLC, Automotive, AEC-Q200 | Tray | Active | 20 F | -20%, +50% | 2.7 V | 18mOhm | 1000 Hrs @ 85°C | PC Pins | Through Hole | Radial, Can | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 0.866" (22.00mm) | -40°C ~ 85°C |
|
SCAP,PBL-0.47/5.4CAP 0.47F 5.4V UCAP PACK |
4 |
|
Datasheet |
PBL | Bulk | Active | 470 mF | - | 5.4 V | 630mOhm @ 1kHz | 1000 Hrs @ 65°C | PC Pins | Through Hole | Radial, Can | 0.472" (12.00mm) | 0.709" L x 0.394" W (18.00mm x 10.00mm) | 0.669" (17.00mm) | -40°C ~ 85°C |
|
JUWT1126MPDCAP 12F 20% 2.7V T/H |
9 |
|
Datasheet |
EVerCAP® JUW | Bulk | Active | 12 F | ±20% | 2.7 V | 400mOhm @ 1kHz | 1000 Hrs @ 70°C | PC Pins | Through Hole | Radial, Can | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 1.319" (33.50mm) | -25°C ~ 70°C |
|
SCAP,PBLL-11.0/5.4CAP 11F -10% +20% 5.4V UCAP PACK |
0 |
|
Datasheet |
PBLL | Bulk | Active | 11 F | -10%, +20% | 5.4 V | 130mOhm @ 1kHz | 1000 Hrs @ 85°C | Wire Leads with Connector | User Defined | Radial, Can | - | 1.516" L x 1.024" W (38.50mm x 26.00mm) | 0.531" (13.50mm) | -40°C ~ 85°C |
|
|
MAL222090002E3CAP 30F -20% +50% 2.7V T/H |
0 |
|
Datasheet |
ENYCAP™ 220 EDLC, Automotive, AEC-Q200 | Tray | Active | 30 F | -20%, +50% | 2.7 V | 26mOhm | 1000 Hrs @ 85°C | PC Pins | Through Hole | Radial, Can | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.319" (33.50mm) | -40°C ~ 85°C |
|
SCAP,PBLS-9.33/8.1CAP 9.33F -10% +20% 8.1V UCAP PK |
0 |
|
Datasheet |
PBLS | Bulk | Active | 9.33 F | -10%, +20% | 8.1 V | 135mOhm | 1000 Hrs @ 65°C | Wire Leads with Connector | User Defined | Module, Wire Leads | - | 1.575" L x 0.551" W (40.00mm x 14.00mm) | 1.811" (46.00mm) | -40°C ~ 65°C |
|
SCAP,PBLS-8.5/10.8CAP 8.5F 10.8V UCAP PACK |
0 |
|
Datasheet |
PBLS | Bulk | Active | 8.5 F | - | 10.8 V | 140mOhm | 1000 Hrs @ 65°C | Wire Leads with Connector | User Defined | Module, Wire Leads | - | 2.047" L x 0.551" W (52.00mm x 14.00mm) | 2.087" (53.00mm) | -40°C ~ 65°C |
|
FT0H335ZFCAP 3.3F -20% +80% 5.5V T/H |
4 |
|
Datasheet |
FT | Bulk | Active | 3.3 F | -20%, +80% | 5.5 V | 1Ohm @ 1kHz | - | PC Pins | Through Hole | Radial, Can | 0.591" (15.00mm) | 1.437" Dia (36.50mm) | 0.591" (15.00mm) | -40°C ~ 85°C |
|
XT3550-3R0287-RCAP 275F -5% +20% 3V T/H |
3 |
|
Datasheet |
XT | Bulk | Active | 275 F | -5%, +20% | 3 V | 4.5mOhm | 1500 Hrs @ 65°C | PC Pins | Through Hole | Radial, Can - Snap-In - 4 Lead | 0.886" (22.50mm) | 1.378" Dia (35.00mm) | 2.126" (54.00mm) | -40°C ~ 65°C |
|
TPLH-2R7/650SL60X51CAP 650F 2.7V CHASSIS STUD MOUNT |
0 |
|
Datasheet |
TPLH-2.7V Threaded | Bulk | Active | 650 F | - | 2.7 V | 0.35mOhm | 1500 Hrs @ 65°C | Screw Terminals | Chassis, Stud Mount | Axial, Can - Screw Terminals | - | 2.362" Dia (60.00mm) | 2.047" (52.00mm) | -40°C ~ 65°C |
|
SM0006-170-NBCAPACITOR 6F 0%/20% 170V CHAS |
0 |
|
Datasheet |
- | Box | Active | 6 F | 0%, +20% | 170 V | 200mOhm | 1500 Hrs @ 65°C | Screw Terminals | Chassis Mount | Module | - | 14.528" L x 9.449" W (369.00mm x 240.00mm) | 3.110" (79.00mm) | -40°C ~ 65°C |
