Digital to Analog Converters (DAC)
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Package/Case | Packaging | Product Status | Programmable | Number of Bits | Number of D/A Converters | Settling Time | Output Type | Differential Output | Data Interface | Reference Type | Voltage - Supply, Analog | Voltage - Supply, Digital | INL/DNL (LSB) | Architecture | Operating Temperature | Supplier Device Package | Mounting Type | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
AD7521KNIC DAC 12BIT A-OUT 18DIP Harris Corporation |
182 |
|
Datasheet |
- | 18-DIP (0.300", 7.62mm) | Bulk | Active | Not Verified | 12 | 1 | 1µs (Typ) | Current - Unbuffered | No | Parallel | External | 5V ~ 15V | 5V ~ 15V | - | R-2R | 0°C ~ 70°C | 18-PDIP | Through Hole | - | - |
|
HI5760/6IBIC DAC 10BIT A-OUT 28SOIC Harris Corporation |
3,738 |
|
Datasheet |
- | 28-SOIC (0.295", 7.50mm Width) | Tube | Obsolete | Not Verified | 10 | 1 | 35ns (Typ) | Current - Unbuffered | Yes | Parallel | External, Internal | 2.7V ~ 5.5V | 2.7V ~ 5.5V | ±0.5, ±0.25 | Current Source | -40°C ~ 85°C | 28-SOIC | Surface Mount | - | - |
|
HI1178JCQIC DAC 8BIT A-OUT 48MQFP Harris Corporation |
7,051 |
|
Datasheet |
- | 48-BQFP | Bulk | Active | Not Verified | 8 | 3 | - | Current - Unbuffered | Yes | Parallel | External | 5V | 5V | ±2.5 (Max), ±0.3 (Max) | - | -40°C ~ 85°C | 48-MQFP (12x12) | Surface Mount | - | - |
|
|
HI5860IBIC DAC 12BIT A-OUT 28SOIC Harris Corporation |
1,000 |
|
Datasheet |
- | 28-SOIC (0.295", 7.50mm Width) | Tube | Obsolete | Not Verified | 12 | 1 | 35ns (Typ) | Current - Unbuffered | Yes | Parallel | External, Internal | 2.7V ~ 5.5V | 2.7V ~ 5.5V | ±0.5, ±0.5 | Current Source | -40°C ~ 85°C | 28-SOIC | Surface Mount | - | - |
|
HI1171JCB-TIC DAC 8BIT A-OUT 24SOIC Harris Corporation |
11,415 |
|
Datasheet |
- | 24-SOIC (0.209", 5.30mm Width) | Bulk | Active | Not Verified | 8 | 1 | 15ns | Current - Unbuffered | Yes | Parallel | External | 5V | 5V | -0.5/+1.3 (Max), ±0.25 (Max) | - | -40°C ~ 85°C | 24-SOIC | Surface Mount | - | - |
|
|
AD7521JNIC DAC 12BIT A-OUT 18DIP Harris Corporation |
4,397 |
|
Datasheet |
- | 18-DIP (0.300", 7.62mm) | Bulk | Active | Not Verified | 12 | 1 | 1µs (Typ) | Current - Unbuffered | No | Parallel | External | 5V ~ 15V | 5V ~ 15V | - | R-2R | 0°C ~ 70°C | 18-PDIP | Through Hole | - | - |
|
HI1177JCQIC DAC 8BIT V OR A-OUT 32MQFP Harris Corporation |
3,505 |
|
Datasheet |
- | 32-TQFP | Bulk | Active | Not Verified | 8 | 2 | - | Voltage or Current - Unbuffered | Yes | Parallel | External | 4.75V ~ 5.25V | 4.75V ~ 5.25V | ±2.5 (Max), ±0.3 (Max) | - | -40°C ~ 85°C | 32-MQFP (7x7) | Surface Mount | - | - |
|
|
HI1106JCPIC DAC 8BIT V-OUT 24DIP Harris Corporation |
1,217 |
|
Datasheet |
- | 24-DIP (0.400", 10.16mm) | Bulk | Active | Not Verified | 8 | 1 | - | Voltage - Unbuffered | No | - | Internal | 4.75V ~ 5.25V | 4.75V ~ 5.25V | ±0.5 (Max), ±0.5 (Max) | - | -20°C ~ 75°C | 24-PDIP | Through Hole | - | - |
|
|
HI1177JCQ-TIC DAC 8BIT V OR A-OUT 32MQFP Harris Corporation |
34,852 |
|
Datasheet |
- | 32-QFP | Bulk | Active | Not Verified | 8 | 2 | - | Voltage and Current | Yes | - | External | 4.75V ~ 5.25V | 4.75V ~ 5.25V | 2.5 (Max), 0.3 (Max) | - | -40°C ~ 85°C | 32-MQFP (7x7) | Surface Mount | - | - |
|
HI20206JCPIC DAC 8BIT A-OUT 42SPDIP Harris Corporation |
144 |
|
Datasheet |
- | 42-SDIP (0.600", 15.24mm) | Bulk | Active | Not Verified | 8 | 3 | 16ns (Typ) | Current - Unbuffered | No | Parallel | Internal | 4.5V ~ 5.5V | 4.5V ~ 5.5V | -, ±0.5 | - | -20°C ~ 85°C | 42-SPDIP | Through Hole | - | - |
