Circular Connector Assemblies
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Series | Packaging | Product Status | Connector Type | Number of Positions | Grade | Qualification | Shell Size - Insert | Shell Size, MIL | Mounting Type | Mounting Feature | Termination | Fastening Type | Orientation | Primary Material | Shell Material | Shell Finish | Contact Finish - Mating | Color | Ingress Protection | Material Flammability Rating | Shielding | Current Rating (Amps) | Voltage Rating | Cable Opening |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
D38999/26JC35PAPLUG |
22 |
|
Datasheet |
Military, MIL-DTL-38999 Series III, Tri-Start™ TV | Bulk | Active | Plug, Male Pins | 22 | - | - | 13-35 | C | Free Hanging (In-Line) | - | Crimp | Threaded | A | Composite | Composite | Olive Drab Cadmium | Gold | Olive Drab | - | - | Shielded | 5A | - | - |
|
|
97-3101A-28-12SMIL-DTL-5015 General Duty Style |
0 |
|
Datasheet |
97 | Bag | Active | Receptacle, Female Sockets | 26 | - | - | 28-12 | - | Free Hanging (In-Line) | - | Solder Cup | Threaded | N (Normal) | Metal | Aluminum Alloy | Olive Drab Cadmium | Silver | Olive Drab | - | UL94 V-0 | Unshielded | 13A | 500VAC, 700VDC | - |
|
|
VG95328D14-12SWJVG95328 12C 8#20 4#16 SKT JAM NU |
17 |
|
Datasheet |
VG95328 | Bag | Active | Receptacle, Female Sockets | 12 | - | - | 14-12 | - | - | - | Crimp | Reverse Bayonet Lock | W | - | - | Zinc-Tin | - | Black | - | - | Shielded | - | - | - |
|
|
D38999/26MC8SNSTRAIGHT PLUG |
23 |
|
Datasheet |
ACT | Bag | Active | Plug, Female Sockets | 8 | Military | MIL-DTL-38999 Series III | 13-8 | C | Free Hanging (In-Line) | - | Crimp | Threaded | N (Normal) | Composite | Composite | Electroless Nickel | Gold | Silver | Environment Resistant | - | Shielded | 7.5A | - | - |
|
MS3108E32-17SCONN PLUG FMALE 4P SILV SLDR CUP |
23 |
|
Datasheet |
MS | Bulk | Active | Plug, Female Sockets | 4 | - | MIL-5015 | 32-17 | - | Free Hanging (In-Line), Right Angle | - | Solder Cup | Threaded | N (Normal) | Metal | Aluminum Alloy | Olive Drab Chromate over Cadmium | Silver | Olive Drab | Environment Resistant | - | Unshielded | - | - | - |
|
|
VG95234N1181SNRECEPTACLE CRIMP 10 CONTACTS |
10 |
|
- |
VG 95234 | Bag | Active | Receptacle, Female Sockets | 10 | - | - | 18-1 | - | Panel Mount | Flange | Crimp | Reverse Bayonet Lock | N (Normal) | Metal | Aluminum Alloy | Olive Drab Cadmium | Silver | Olive Drab | IP67 - Dust Tight, Waterproof | - | Shielded | 22A | 50V | 0.575" (14.60mm) |
|
|
PT08E-14-15S(SR)MIL-26482 MS/PT/CMB PLUG |
14 |
|
Datasheet |
PT | Bag | Active | Plug, Female Sockets | 15 | - | MIL-DTL-26482 Series I | 14-15 | - | Free Hanging (In-Line), Right Angle | - | Solder Cup | Bayonet Lock | N (Normal) | Metal | Aluminum | Olive Drab Chromate over Cadmium | Gold | Olive Drab | Environment Resistant | - | Unshielded | 7.5A, 13A | 600VAC | 1.171" (29.74mm) |
|
|
D38999/26JB2SNPLUG |
25 |
|
Datasheet |
Military, MIL-DTL-38999 Series III, Tri-Start™ TV | Bulk | Active | Plug, Female Sockets | 2 | - | - | 11-2 | B | Free Hanging (In-Line) | - | Crimp | Threaded | N (Normal) | Composite | Composite | Olive Drab Cadmium | Gold | Olive Drab | - | - | Shielded | 13A | - | - |
|
|
EM40M-WBP-1PCA-K(81)PLUG, MALE, 410A, PUSH-ON BAYONE |
11 |
|
Datasheet |
EM40M | Bag | Active | Plug, Male Pins | 1 | - | - | 40 | - | Free Hanging (In-Line) | - | Crimp, Screw | Bayonet Lock | Keyed | Plastic | Polybutylene Terephthalate (PBT) | - | Silver | Black | Waterproof | UL94 V-0 | Unshielded | 300A | 600VAC/DC, 1000VAC/DC | - |
|
|
D38999/20MD35PCWALL MOUNT RECEPTACLE |
25 |
|
Datasheet |
- | Bag | Active | Receptacle, Male Pins | 37 | Military | MIL-DTL-38999 Series III | 15-35 | D | Panel Mount | Flange | Crimp | Threaded | C | Composite | Composite | Electroless Nickel | Gold | Silver | IP67 - Dust Tight, Waterproof | - | Shielded | 5A | - | - |
|
|
97-3106A-24-11P(621)MIL-DTL-5015 General Duty Style |
0 |
|
Datasheet |
97 | Bag | Active | Plug, Male Pins | 9 | - | - | 24-11 | - | Free Hanging (In-Line) | - | Solder Cup | Threaded | N (Normal) | Metal | Aluminum Alloy | Black Zinc Alloy | Silver | Black | - | UL94 V-0 | Unshielded | 23A, 46A | 500VAC, 700VDC | - |
|
|
D38999/20MD35PAWALL MOUNT RECEPTACLE |
19 |
|
Datasheet |
ACT | Bag | Active | Receptacle, Male Pins | 37 | Military | MIL-DTL-38999 Series III | 15-35 | D | Panel Mount | Flange | Crimp | Threaded | A | Composite | Composite | Electroless Nickel | Gold | Silver | Environment Resistant | - | Shielded | 5A | - | - |
|
|
D38999/20JE8PAWALL MOUNT RECEPTACLE |
25 |
|
Datasheet |
ACT | Bag | Active | Receptacle, Male Pins | 8 | Military | MIL-DTL-38999 Series III | 17-8 | E | Panel Mount | Flange | Crimp | Threaded | A | Composite | Composite | Olive Drab Cadmium | Gold | Olive Drab | Environment Resistant | - | Shielded | 13A | - | - |
|
|
MS3106A36-5SCONN PLUG FMALE 4P SILV SLDR CUP |
22 |
|
Datasheet |
MS | Bulk | Active | Plug, Female Sockets | 4 | - | MIL-DTL-5015 | 36-5 | - | Free Hanging (In-Line) | - | Solder Cup | Threaded | N (Normal) | Metal | Aluminum Alloy | Olive Drab Chromate over Cadmium | Silver | Olive Drab | - | - | Unshielded | - | - | - |
|
|
97-3107A-18-12PMIL-DTL-5015 General Duty Style |
0 |
|
Datasheet |
97 | Bag | Active | Plug, Male Pins | 6 | - | - | 18-12 | - | Free Hanging (In-Line) | - | Solder Cup | Push-Pull | N (Normal) | Metal | Aluminum Alloy | Olive Drab Cadmium | Silver | Olive Drab | IP67 - Dust Tight, Waterproof | UL94 V-0 | Unshielded | 13A | 500VAC, 700VDC | - |
|
|
MS27473T10B35SAPLUG |
16 |
|
Datasheet |
JT | Bag | Active | Plug, Female Sockets | 13 | Military | MIL-DTL-38999 Series II | 10-35 | - | Free Hanging (In-Line) | - | Crimp | Bayonet Lock | A | Metal | Aluminum | Olive Drab Cadmium over Nickel | Gold | Olive Drab | Environment Resistant | - | Unshielded | - | - | - |
|
|
MS3126E12-8SMIL-26482 MS/PT/CMB PLUG |
10 |
|
Datasheet |
PT | Bag | Active | Plug, Female Sockets | 8 | Military | MIL-DTL-26482 Series I | 12-8 | - | Free Hanging (In-Line) | - | Crimp | Bayonet Lock | N (Normal) | Metal | Aluminum | Olive Drab Chromate over Cadmium | Gold | Olive Drab | Environment Resistant | - | Unshielded | 7.5A | 600VAC | - |
|
|
GTS06F-20-3PCONN PLUG MALE 3P SILV SLDR CUP |
22 |
|
Datasheet |
GT | Bulk | Active | Plug, Male Pins | 3 | - | MIL-5015 Derivative | 20-3 | - | Free Hanging (In-Line) | - | Solder Cup | Reverse Bayonet Lock | N (Normal) | Metal | Aluminum | Olive Drab Cadmium | Silver | Olive Drab | IP67 - Dust Tight, Waterproof | - | Unshielded | - | - | - |
|
|
MS3126F20-39PMIL-26482 MS/PT/CMB PLUG |
25 |
|
Datasheet |
PT | Bag | Active | Plug, Male Pins | 39 | Military | MIL-DTL-26482 Series I | 20-39 | - | Free Hanging (In-Line) | - | Crimp | Bayonet Lock | N (Normal) | Metal | Aluminum | Olive Drab Chromate over Cadmium | Gold | Olive Drab | Environment Resistant | - | Unshielded | 7.5A, 13A | 600VAC | 0.625" (15.88mm) |
|
|
MS3110F14-19SMIL-26482 MS/PT/CMB RECEPT |
10 |
|
Datasheet |
PT | Bag | Active | Receptacle, Female Sockets | 19 | Military | MIL-DTL-26482 Series I | 14-19 | - | Panel Mount | Flange | Solder Cup | Bayonet Lock | N (Normal) | Metal | Aluminum | Olive Drab Chromate over Cadmium | Gold | Olive Drab | Environment Resistant | - | Unshielded | 7.5A | 600VAC | - |
Circular Connector Assemblies Electronic Components
Explore Circular Connector Assemblies electronic components, related subcategories, product specifications, datasheets and sourcing options. We support original component procurement, BOM sourcing and RFQ services for engineers, distributors and global buyers.
Frequently Asked Questions
Q1: What products are included in Circular Connector Assemblies?
This category includes related Circular Connector Assemblies subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Circular Connector Assemblies components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Circular Connector Assemblies and other electronic components.
