Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
MAL213668681E3CAP ALUM 680UF 20% 63V RADIAL TH |
0 |
|
Datasheet |
136 RVI | Bulk | Active | 680 µF | ±20% | 63 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 850 mA @ 100 Hz | - | 46 mOhms | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
|
MAL213669331E3CAP ALUM 330UF 20% 100V RADIAL |
0 |
|
Datasheet |
136 RVI | Bulk | Active | 330 µF | ±20% | 100 V | - | 10000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 800 mA @ 100 Hz | - | 58 mOhms | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
PEH536SAC3150M2SCAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
PEH536 | Box | Active | 150 µF | ±20% | 250 V | 660mOhm @ 100Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 600 mA @ 100 Hz | 5.3 A @ 20 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
PEH536SAC3150M2CAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
PEH536 | Box | Active | 150 µF | ±20% | 250 V | 660mOhm @ 100Hz | 4600 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 600 mA @ 100 Hz | 5.3 A @ 20 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
450PK100MEFCGC18X40CAP ALUM 100UF 20% 450V RADIAL |
0 |
|
Datasheet |
PK | Tape & Box (TB) | Active | 100 µF | ±20% | 450 V | - | 2000 Hrs @ 85°C | -25°C ~ 85°C | Polar | - | General Purpose | 280 mA @ 120 Hz | 336 mA @ 10 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
EEU-TA1J471SCAP ALUM 470UF 20% 63V RADIAL TH |
0 |
|
Datasheet |
TA | Bulk | Active | 470 µF | ±20% | 63 V | - | 2000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | 1.493 A @ 120 Hz | 1.99 A @ 100 kHz | 60 mOhms | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
|
ELG157M400AS2AACAP ALUM SNAP-IN 105C |
0 |
|
Datasheet |
ELG | Bulk | Active | 150 µF | ±20% | 400 V | - | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 850 mA @ 120 Hz | 1.2325 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
LSG181M2P---2530SCAP ALUM 420V POLAR |
0 |
|
- |
LSG | Active | 180 µF | ±20% | 420 V | 1.106Ohm @ 120Hz | 2000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 770 mA @ 120 Hz | 1.1011 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | ||
|
UFG1E332MHMCAP ALUM 3300UF 20% 25V RADIAL |
0 |
|
Datasheet |
UFG | Bulk | Obsolete | 3300 µF | ±20% | 25 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 1.794 A @ 120 Hz | 2.0631 A @ 10 kHz | - | 0.295" (7.50mm) | 0.709" Dia (18.00mm) | 1.654" (42.00mm) | - | Through Hole | |
|
|
PEH506YBB2680M2CAP ALUM SNAP-IN 85C |
0 |
|
Datasheet |
PEH506 | Box | Active | 68 µF | ±20% | 450 V | 1.3Ohm @ 100Hz | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 800 mA @ 100 Hz | 3.4 A @ 100 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.063" (27.00mm) | - | Through Hole | |
|
|
ELH228M080AR2AACAP ALUM SNAP-IN 85C |
0 |
|
Datasheet |
ELH | Bulk | Active | 2.2 mF | ±20% | 80 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.45 A @ 120 Hz | 2.842 A @ 10 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.260" (32.00mm) | - | Through Hole | |
|
|
LSG682M1H---3030SCAP ALUM 50V POLAR |
0 |
|
- |
LSG | Active | 6.8 mF | ±20% | 50 V | 68mOhm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.84 A @ 120 Hz | 3.408 A @ 10 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.260" (32.00mm) | - | Through Hole | ||
|
UFG0J472MHMCAP ALUM 4700UF 20% 6.3V RADIAL |
0 |
|
Datasheet |
UFG | Bulk | Obsolete | 4700 µF | ±20% | 6.3 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | Audio | 1.431 A @ 120 Hz | 1.64565 A @ 10 kHz | - | 0.295" (7.50mm) | 0.630" Dia (16.00mm) | 1.319" (33.50mm) | - | Through Hole | |
|
SLP472M050A4P3CAP ALUM 4700UF 20% 50V SNAP TH |
0 |
|
Datasheet |
SLP0712TE (750W) | Bulk | Active | 4700 µF | ±20% | 50 V | 99mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 2.5 A @ 120 Hz | 3.13 A @ 20 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.772" (45.00mm) | - | Through Hole | |
|
SLP153M025E5P3CAP ALUM 15000UF 20% 25V SNAP TH |
0 |
|
Datasheet |
SLP0712TE (750W) | Bulk | Active | 15000 µF | ±20% | 25 V | 40mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 3.6 A @ 120 Hz | 4.5 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 1.378" (35.00mm) | - | Through Hole | |
|
SLPX821M180C5P3CAP ALUM 820UF 20% 180V SNAP TH |
0 |
|
Datasheet |
SLPX | Bulk | Active | 820 µF | ±20% | 180 V | 243mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.75 A @ 120 Hz | 4.04 A @ 20 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.378" (35.00mm) | - | Through Hole | |
|
|
SLPX822M050C4P3CAP ALUM 8200UF 20% 50V SNAP TH |
0 |
|
Datasheet |
SLPX | Bulk | Active | 8200 µF | ±20% | 50 V | 57mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 4.44 A @ 120 Hz | 5.55 A @ 20 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.772" (45.00mm) | - | Through Hole | |
|
SLP122M100A5P3CAP ALUM 1200UF 20% 100V SNAP TH |
0 |
|
Datasheet |
SLP0712TE (750W) | Bulk | Active | 1200 µF | ±20% | 100 V | 221mOhm @ 120Hz | 3000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.69 A @ 120 Hz | 2.11 A @ 20 kHz | - | 0.394" (10.00mm) | 0.866" Dia (22.00mm) | 1.378" (35.00mm) | - | Through Hole | |
|
SLPX471M220E1P3CAP ALUM 470UF 20% 220V SNAP TH |
0 |
|
Datasheet |
SLPX | Bulk | Active | 470 µF | ±20% | 220 V | 423mOhm @ 120Hz | 3000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 2.16 A @ 120 Hz | 3.18 A @ 20 kHz | - | 0.394" (10.00mm) | 1.181" Dia (30.00mm) | 0.984" (25.00mm) | - | Through Hole | |
|
SLP271M250C3P3CAP ALUM 270UF 20% 250V SNAP TH |
0 |
|
Datasheet |
SLP0712TE (750W) | Bulk | Active | 270 µF | ±20% | 250 V | 737mOhm @ 120Hz | 3000 Hrs @ 105°C | -25°C ~ 105°C | Polar | - | General Purpose | 1.27 A @ 120 Hz | 1.87 A @ 20 kHz | - | 0.394" (10.00mm) | 0.984" Dia (25.00mm) | 1.181" (30.00mm) | - | Through Hole |
Aluminum Electrolytic Capacitors Electronic Components
Frequently Asked Questions
Q1: What products are included in Aluminum Electrolytic Capacitors?
This category includes related Aluminum Electrolytic Capacitors subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Aluminum Electrolytic Capacitors components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Aluminum Electrolytic Capacitors and other electronic components.
