Aluminum Electrolytic Capacitors
| Photo | Mfr. Part # | Availability | Quantity | Datasheet | Package/Case | Series | Packaging | Product Status | Capacitance | Tolerance | Voltage - Rated | ESR (Equivalent Series Resistance) | Lifetime @ Temp. | Operating Temperature | Polarization | Ratings | Applications | Ripple Current @ Low Frequency | Ripple Current @ High Frequency | Impedance | Lead Spacing | Size / Dimension | Height - Seated (Max) | Surface Mount Land Size | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
RAVVZ331M1GFH5002Y1UELECTRIC DOUBLE LAYER CAPACITOR |
0 |
|
Datasheet |
- | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
EXV686M050A9PAACAP ALUM 68UF 20% 50V SMD |
0 |
|
Datasheet |
EXV | Tape & Reel (TR) | Active | 68 µF | ±20% | 50 V | 340mOhm @ 100kHz | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 469 mA @ 120 Hz | 670 mA @ 100 kHz | 340 mOhms | - | 0.394" Dia (10.00mm) | 0.413" (10.50mm) | 0.406" L x 0.406" W (10.30mm x 10.30mm) | Surface Mount | |
|
AHA476M50X16B-FCAP ALUM 47UF 20% 50V SMD |
0 |
|
Datasheet |
AHA | Bulk | Obsolete | 47 µF | ±20% | 50 V | 4.2Ohm @ 120Hz | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive, Bypass, Decoupling | 63 mA @ 120 Hz | 107.1 mA @ 10 kHz | - | - | 0.248" Dia (6.30mm) | 0.303" (7.70mm) | 0.260" L x 0.260" W (6.60mm x 6.60mm) | Surface Mount | |
|
AVEK107M10F24T-FCAP ALUM 100UF 20% 10V SMD |
0 |
|
Datasheet |
AVEK | Tape & Reel (TR) | Obsolete | 100 µF | ±20% | 10 V | 4.3Ohm @ 120Hz | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 178 mA @ 120 Hz | 222.5 mA @ 10 kHz | - | - | 0.315" Dia (8.00mm) | 0.413" (10.50mm) | 0.331" L x 0.331" W (8.40mm x 8.40mm) | Surface Mount | |
|
|
AVEK476M25F24T-FCAP ALUM 47UF 20% 25V SMD |
0 |
|
Datasheet |
AVEK | Tape & Reel (TR) | Obsolete | 47 µF | ±20% | 25 V | 5.6Ohm @ 120Hz | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 178 mA @ 120 Hz | 249.2 mA @ 10 kHz | - | - | 0.315" Dia (8.00mm) | 0.413" (10.50mm) | 0.331" L x 0.331" W (8.40mm x 8.40mm) | Surface Mount | |
|
|
AVGA337M10F24T-FCAP ALUM 330UF 20% 10V SMD |
0 |
|
Datasheet |
AVGA | Tape & Reel (TR) | Obsolete | 330 µF | ±20% | 10 V | 1.76Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 290 mA @ 120 Hz | - | - | - | 0.315" Dia (8.00mm) | 0.413" (10.50mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount | |
|
|
AVGA477M06F24T-FCAP ALUM 470UF 20% 6.3V SMD |
0 |
|
Datasheet |
AVGA | Tape & Reel (TR) | Obsolete | 470 µF | ±20% | 6.3 V | 1.59Ohm @ 120Hz | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 320 mA @ 120 Hz | - | - | - | 0.315" Dia (8.00mm) | 0.413" (10.50mm) | 0.327" L x 0.327" W (8.30mm x 8.30mm) | Surface Mount | |
|
KY16VB152M10X30LLCAP ALUM 1500UF 20% 16V RADIAL |
0 |
|
- |
KY | Bulk | Active | 1500 µF | ±20% | 16 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 1.146 A @ 120 Hz | 1.91 A @ 100 kHz | 31 mOhms | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 1.181" (30.00mm) | - | Through Hole | |
|
UPX1V330MPDCAP ALUM 33UF 20% 35V RADIAL TH |
0 |
|
Datasheet |
UPX | Bulk | Not For New Designs | 33 µF | ±20% | 35 V | - | 20000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 283.5 mA @ 120 Hz | 378 mA @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole | |
|
160YXF12KEFC10X12.5CAP ALUM 12UF 10% 160V RADIAL TH |
0 |
|
Datasheet |
YXF | Bulk | Not For New Designs | 12 µF | ±10% | 160 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole | |
|
|
160YXF12KEFCT810X12.5CAP ALUM 12UF 10% 160V RADIAL TH |
0 |
|
Datasheet |
YXF | Tape & Box (TB) | Not For New Designs | 12 µF | ±10% | 160 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | - | - | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole | |
|
50YXH220MEFCT810X16CAP ALUM 220UF 20% 50V RADIAL TH |
0 |
|
Datasheet |
YXH | Tape & Box (TB) | Last Time Buy | 220 µF | ±20% | 50 V | - | 7000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 525 mA @ 120 Hz | 1.05 A @ 100 kHz | 84 mOhms | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.689" (17.50mm) | - | Through Hole | |
|
35ZT100M8X11.5CAP ALUM 100UF 20% 35V RADIAL TH |
0 |
|
Datasheet |
ZT | Bulk | Obsolete | 100 µF | ±20% | 35 V | - | 2000 Hrs @ 125°C | -40°C ~ 125°C | Polar | - | General Purpose | 190 mA @ 120 Hz | 760 mA @ 100 kHz | 94 mOhms | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.512" (13.00mm) | - | Through Hole | |
|
EKMQ251ELL3R3MF11DCAP ALUM 3.3UF 20% 250V RADIAL |
0 |
|
Datasheet |
KMQ | Bulk | Active | 3.3 µF | ±20% | 250 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 28 mA @ 120 Hz | 70 mA @ 100 kHz | - | 0.098" (2.50mm) | 0.248" Dia (6.30mm) | 0.492" (12.50mm) | - | Through Hole | |
|
|
ESMQ101ELL680MJC5SCAP ALUM 68UF 20% 100V RADIAL TH |
0 |
|
Datasheet |
SMQ | Bulk | Active | 68 µF | ±20% | 100 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 270 mA @ 120 Hz | 486 mA @ 100 kHz | - | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.551" (14.00mm) | - | Through Hole | |
|
|
UPM1K470MPD6CVCAP ALUM 80V POLAR |
0 |
|
- |
UPM | Bulk | Active | 47 µF | ±20% | 80 V | - | 5000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 245 mA @ 120 Hz | 410 mA @ 10 kHz | 420 mOhms | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 0.492" (12.50mm) | - | Through Hole | |
|
|
UCD1J470MCL1GSCAPACITOR |
0 |
|
- |
- | Tape & Reel (TR) | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
|
515D476M050AA6AE3CAP ALUM 47UF 20% 50V RADIAL TH |
0 |
|
Datasheet |
515D | Bulk | Obsolete | 47 µF | ±20% | 50 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 150 mA @ 120 Hz | 300 mA @ 10 kHz | - | 0.098" (2.50mm) | 0.248" Dia (6.30mm) | 0.433" (11.00mm) | - | Through Hole | |
|
|
RXK221M1JBK-1025SCAP ALUM 63V POLAR |
0 |
|
- |
RXK | Active | 220 µF | ±20% | 63 V | - | 4000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 648 mA @ 120 Hz | 925 mA @ 100 kHz | 130 mOhms | 0.197" (5.00mm) | 0.394" Dia (10.00mm) | 1.063" (27.00mm) | - | Through Hole | ||
|
UPA1A102MPDCAP ALUM 1000UF 20% 10V RADIAL |
0 |
|
Datasheet |
UPA | Bulk | Active | 1000 µF | ±20% | 10 V | - | 3000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 915 mA @ 120 Hz | 1.22 A @ 100 kHz | 44 mOhms | 0.138" (3.50mm) | 0.315" Dia (8.00mm) | 0.866" (22.00mm) | - | Through Hole |
Aluminum Electrolytic Capacitors Electronic Components
Frequently Asked Questions
Q1: What products are included in Aluminum Electrolytic Capacitors?
This category includes related Aluminum Electrolytic Capacitors subcategories and electronic components from multiple manufacturers. Select a lower-level category to view available part numbers.
Q2: Can I request a quotation for Aluminum Electrolytic Capacitors components?
Yes. Send us the part numbers and required quantities, and our team will provide sourcing and quotation support.
Q3: Are datasheets and technical information available?
Yes. Datasheets and technical information are available on supported final product pages and product listings.
Q4: Do you support BOM sourcing?
Yes. We support BOM matching, component procurement and alternative sourcing for Aluminum Electrolytic Capacitors and other electronic components.
